Specifications
Brand Name :
Shichuangxinke
Model Number :
SCXK-P16
Certification :
CE RoHS FCC CCC TUV UL
Place of Origin :
China ,Guang Dong
MOQ :
negotiation
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after deposit payment received
Packaging Details :
wooden box flight case, wooden case, carton, it is up to you.
Resolution/mm :
16
Pixel configuration :
1R1G1B
Scanning Mode :
static full color
Module Size :
256x256mm
cabinet size :
1024x1024mm
certificates :
CE RoHS FCC CCC UL
application :
stadium,airport,shopping mall,street advertising
material :
aluminum
warranty :
3-5 years
Description

exterior P16 DIP LED sign screen,high definition road billboard

Specifications :

outdoor DIP P16
Resolution/mm 16
Pixel configuration 1R1G1B
Pixel density/pixels/m² 3906/m²
Module resolution 16x16
Module size/mm 256x256mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode static full color
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Trainning Service:

The training class is mainly to assure customer have good used the products. It needs both of the buyer and seller to work along with the contract. Seller is responsible for training buyers how to operate the software of LED screen and some basic hardware mantenance knowledge. When installing and testing are being well-finished, the detailed training class informations as below:


1. The basic operation principal


2. Procedures and managements of system operation


3.The daily maintenance and safety caution


4. System software installation


5. Simple software failure treatment


6. Simple hardware failure treatment
