Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display
Specifications
Brand Name :
Shichuangxinke
Model Number :
SCXK-P4
Certification :
CE RoHS FCC CCC TUV UL
Place of Origin :
China ,Guang Dong
MOQ :
1 square meters
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, D/P, D/A, MoneyGram
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after deposit payment received
Packaging Details :
wooden box flight case, wooden case, carton, it is up to you.
Resolution/mm :
4
Pixel configuration :
1R1G1B
Scanning Mode :
1/8 scanning
Module Size :
256x128MM
cabinet size :
512x512MM
certificates :
CE RoHS FCC CCC UL
application :
stadium,airport,shopping mall,street advertising
material :
aluminum
warranty :
3-5 years
Description

SMD P4 Waterproof Outdoor Billboard Advertising , Road LED Screen Display

Specifications :

outdoor SMD P4
Resolution/mm 4
Pixel configuration 1R1G1B
Pixel density/pixels/m² 62500/m²
Module resolution 256x128
Module size/mm 512x512MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Features:

1. Excellent visual effect, better viewing effect for text and graphic or video
2. Large viewing angle,both H/V can reach 110 degree;getting vivid effect within any position of the viewing range;
3. High contrast ratio and good evenness, high uniformity,without mosaic
4. Resist of the high temperature and antioxidation and anti-statiic;
5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince.
6. Long using life & MTBF

our services

1.We provide 24-hours service,and every message you quote inquiry will be replied within 12 hours.

2.Our products are exported to foreign countries and regions. 3.Our professional team will constantly communicate with you,to establish a good working relationship.We contact you by e-mail and phone,always prepared to help you out.

Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display

Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display

Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen DisplayDie-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display

Die-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen DisplayDie-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen DisplayDie-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen DisplayDie-Cast Aluminum Screen SMD P4 Waterproof Outdoor Billboard, Road LED Screen Display

FAQ

Q. Can this LED display be installed permanently outside? ---A. A series LED panel is for events use. It has no problem to be used outdoor for events. But if need long time used outdoor, such as install on truck or trailer, it is better to buy fixed LED display.

Q. How long time is needed to produce? ---A. Our production time is 7-15 working days. We have 500sqm indoor P3.91 led display stock now, delivery time is 3 days.

Q. How long does shipping take? ---A. Express and air shipping usually take 5-10 days. Sea shipping takes about 15-55 days according to different country.

Q. What trade terms do you support? ---A. We usually do FOB, CIF, DDU, DDP, EXW terms.

Q. This is the first time to import, I don’t know how to do. ---A. We offer DDP door to door service, you just need to pay us, then wait to receive order.

Q. Do I need to buy other equipment to install LED screen? ---A. You just need to prepare power distribution box, truss and installation tool. We also offer one stop purchase if you want. We can also offer stage lights and speaker.

Q.What is LED screen common size? --A. 16:9 and 4:3 aspect ratio is popular.
