Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness
Specifications
Brand Name :
SCX
Model Number :
P3 outdoor led scoreboard
Certification :
CE ROHS FCC
Place of Origin :
China
MOQ :
negotiate
Price :
negotiate
Payment Terms :
T/T, Western Union
Delivery Time :
5-10days
Packaging Details :
wooden/flight cases
Module size :
192*192mm
Cabinet size :
960*960mm
Waterproof :
IP65
Warranty :
3 years
Control system :
Nova star
Brightness :
5000cd
Description

P3 outdoor led scoreboard cabinet size 960*960mm with high brightness

♦ Modular assemby, simple and easy to set up.

♦ installation mode

Suspending and stacking installation, fully match the events installation methods.

♦ Product specification

indoor SMD P3
Lamp size 2020
Resolution/mm 3
Pixel configuration RGB 3 in 1
Pixel density/pixels/sqm 111111/sqm
Module resolution 64x64
Module size/mm 192x192
View distance ≥2m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >2500cd/sqm
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/16
Frame rate 60Hz
Refresh frequency >4200Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/sqm <1000W
Average power:/sqm <280W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)
Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Cabinet Size 960x960mm P3 Outdoor Led Scoreboard With High Brightness

♦ Production process:

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.

♦ Why choose us:

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.

Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.

Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.
