Specifications
Brand Name :
SCXK
Model Number :
P3
Certification :
CE/ROHS/FCC/ISO
Place of Origin :
China
MOQ :
5
Price :
USD560-632per square meters
Payment Terms :
T/T, Western Union, MoneyGram,
Supply Ability :
5000sqm per month
Delivery Time :
7-10 working days after deposit payment received
Packaging Details :
wooden box flight case, wooden case, carton, it is up to you.
Pixel Pitch :
p3
Usage :
Indoor
Module size :
192x192mm
Cabinet size :
576mm*576mm
Pixel density :
111111 dots/sqm
Scanning mode :
1/32 scanning
Warranty :
3years
Display Function :
Video
LED Shape & Size :
2mm SMD2121
Life time :
10 years
Description

P3 Full color indoor led display led screen panel led video wall with Resolution HD Epistar 1/32 Scan

Specifications :

Indoor Full Color P3 LED Display
Resolution/mm 3
Pixel configuration 1R1G1B
Pixel density/pixels/m² 111111/square meter
Module resolution 64x64
Module size/mm 192x192MM
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >5000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/32 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

Advantages:

1. High-strength and precision die-cast aluminum cabinet, seamless installation.

2. Ultra light and ultra thin, it is more convenient transport and save shipping cost.

3. Unique design, easy to assembly and disassembly.

4. Two side quick lock, which makes screen a better flatness and stable.

5. Adopted pure black leds, high contrast ratio, pictures more clear and vivid.

6. High refresh rate, >=3840HZ. No flicker.

Our Results:

Packaging & Shipping

Our Services

1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information.

Company Information

FAQ

Welcome to visit our website and inquire us more info,waiting for you all the time!!!

Contact Info:

Sales engineer Lillian
Mob +86 15073669571
Wechat/whatspp 15073669571
