Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Outdoor Full Color LED Display P8mm HD IP65 Fixed Installation
Specifications
Brand Name :
SCX
Model Number :
SCX-P8
Certification :
CE,ISO,RoHs,FCC
Place of Origin :
China(Mainalnd)
MOQ :
5sqm
Price :
399-599USD/sqm
Payment Terms :
T/T, Western Union
Supply Ability :
5000sqm/month
Delivery Time :
12-15 working days.
Packaging Details :
Carton,wooden and flight cases.
Pixels :
8mm
Usage :
Outdoor
Warranty :
3 Years
Module size :
256*128 mm
Product name :
Led Video Display Panel
Brightness :
6000nits
Led chip :
Epistar
Life span :
100000hours
Description
  Pixel Panels Outdoor Full Color LED Display P8 HD High Quality IP65 Fixed Installation     Outdoor LED Screen Series:     1.Automatic brightness control, super processing ability, strong color restoration.    2. High brightness, even in direct, full-on sunlight to ensure you attract more audience to  get short ROI of your full color outdoor led display screen's investment.    3.Support various interfaces and signal sources.    4.Advanced digital control technology, excellent effect.    5. Antiseptic and durable, can be used outdoors in all weather.    Specifications:
Resolution/mm 8
Pixel configuration 1R1G1B
Pixel density/pixels/m² 15625dots/quare meter
Module resolution 32x16
Module size/mm 256x128
View distance 8-50m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 6000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4
Frame rate 60Hz
Refresh frequency 1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/square meter <800W
Average power:/square meter <280W
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%


Outdoor Full Color LED Display P8mm HD IP65 Fixed InstallationOutdoor Full Color LED Display P8mm HD IP65 Fixed InstallationOutdoor Full Color LED Display P8mm HD IP65 Fixed Installation
