Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Rental Die Cast Aluminum Large Outdoor LED Display Video Panel P6.67 IP65 2-3 Years Warranty
Specifications
Brand Name :
SCX
Model Number :
SCX-P6.67
Certification :
CE,ISO,FCC,UL
Place of Origin :
China(Mainland)
MOQ :
3 sqm
Payment Terms :
T/T, Western Union
Supply Ability :
5000sqm/month
Delivery Time :
12-15 working days.
Packaging Details :
Carton,wooden and flight cases.
Pixels :
6.67mm
Usage :
Outdoor
Screen dimension :
Customized
Tube chip color :
Full Color
Display function :
Video
Brightness :
5500nits
Warranty :
2-3 Years
Life span :
100000hours
Scan mode :
1/8 scan
Cabinet material :
Iron or aluminum
Description

P6.67 Outdoor Full Color LED Display High Quality Video Panel IP65

Features:

1: Adopting Taiwan Epistar's large LED chip, the brightness is more than 5500nits;

2: High Color Output: 16-bit color, so the video and images displayed on the LED screen are very fresh and vivid.

It can attract more viewers' eyes and make your advertisement very effective.

3: High refresh rate, more than 3840HZ/S; no scan lines when taking photos or videos.

4 High waterproof function: IP65 on the front side, IP54 on the back side. Our cabinet has a special cover on the back door, no need

to make an extra frame to protect the back side waterproof.

Specifications:

SMD P6.67
Resolution/mm 6.67
Pixel configuration 1R1G1B
Pixel density/pixels/m² 22478dots/square meter
Module resolution 48x24mm
Module size/mm 320x160mm
View distance 7-50m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 5500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/8 SCANNING
Frame rate 60Hz
Refresh frequency 1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%
