Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation
Specifications
Brand Name :
Fair Machinery
Model Number :
FMP-01
Certification :
CE.ISO
Place of Origin :
Zhengzhou,China
MOQ :
1 set
Price :
900-1500 USD/set
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P,Pyple
Supply Ability :
1000-2000 sets/month
Delivery Time :
3-7days
Packaging Details :
wooden case packing,1200*670*1200mm
name :
valve bag filling machine
Automatic Grade :
Automatic
Driven Type :
Electric
Weight :
195kg
Weighing Scope: :
10~60kg, adjustable on panel.
Measuring accuracy: :
±0.2-0.4%
Air Requirements: :
0.4-0.8MPa ( dry compressed air
Storage temperature: :
-20℃~60℃
Description

Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation

Product Description:

Our cement sand packing machine(valve bag packing machine), the improved model of the latest development ,different from other factory production. We improve its most precise measurement sensing system, changed the way of lifting force sensor, the industry generally used, to the pressure sensing mode, making the packing machine life and accuracy greatly improved, Bag weight error from the original error of ± 0.5-1kg reach ± 0.25kg. Filling mouth also made design changes, adding a "gas returning nozzle" design, in the filling process the bag excess gas can be discharged, so that the filling process more smoothly.

Item

FMP-01 valve bag packing machine

Weighing Scope

10~60kg, adjustable on panel.

Discharge Port Qty.

1 pic

Capacity

8-12 t/h

Motor Power

3kw

Measuring accuracy

±0.2-0.4％

Bag weight qualified rate

>95%

Weighing device

Micro-computer

Overall dimension(mm)

1200*670*1200

Air Requirements

0.4-0.8MPa ( dry compressed air)

Application Environment

Operating temperature

0℃～50℃

Storage temperature

-20℃～60℃

Overview

Type: Filling Machine

Condition: New

Application: Chemical, Commodity, Food, Machinery & Hardware, dry mortar, other powder, granular materials

Packaging Type: Bags, Pouch

Packaging Material: dry mortar, other powder, granular materials

Automatic Grade: Automatic

Driven Type: Electric

Voltage: 380V - 440V or customized

Power: 3KW

Place of Origin: Henan, China (Mainland)

Brand Name: Fair Machinery

Model Number: FMP-01

Dimension(L*W*H): 1170*770*1160mm

Weight: 200kg

Certification: CE ISO9001:2008

After-sales Service Provided: Engineers available to service machinery overseas

Product name: valve port packing machine

Color: Blue or customized

Bag weight error: <0.1%

Packing speed: 4 - 8s/bag

Single bag weight: 15 - 50kg availiable

Air Pressure: 0.5 - 0.8Mpa

Function: Filling Sealing Forming

Product Type: impeller or screw

Automatic grade: automatic

Single-mouth power: 3kw

Operating temperature: 0℃~50℃

Automatic Weighing And Packaging Machine Dry Mortar Packing Machine Simple Operation

Main Features

I. Valve Port Packaging Machine adopts LN965A15-J weighing controller, which is a precision intelligent instrument, whose main function is providing quantitative automatic control after for the valve port packing machine such as chemical, cement and food so on.

II. The advantages are: easy operation, easy calibration, stable performance, double valve and high precision. It adopts dual-panel design with good anti-jamming capability, which can be used reliably in complex and harsh environments.

Packaging & Delivery
1. The machines will be packed with bubble wrap or wooden boxes.
2. The empty container will be delivered from the port to the factory.
3. The machines-loaded will be made in the factory.
4. All of the machines in the container will be fixed by steel ropes.
5. Then the machines and containers will be sent to the port.

Port

Qingdao,Tianjin, Shanghai or others are availiable

Lead Time :

Shipped in 7 days after payment
