Specifications
Brand Name :
Fair Machinery
Model Number :
FMZZ-10T
Certification :
CE, ISO
Place of Origin :
Zhengzhou,China
MOQ :
1 set
Price :
3000-35000 USD/set
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
1000sets/month
Delivery Time :
3-7 work days
Packaging Details :
nuding packing / 4400x1700x2560mm /1300kg
Stirring Speed :
21 r/min
Max. Loading Capacity: :
5-15 t/h
Product Type :
Mixing Machine
Mixer Type :
ribbon blender
Usage :
Mixing
Material :
carbon steel /stainless steel
Description

Professional Energy-Saving Lacquer Mixer,Stone Finish Paint Blender,Stone-Like Paint Equipment

Product Description

Stone-like paint, texture paint, sand paint, floor paint, rock paint, relief paint, rock chip paint, texturing paint, putty paste and other thick paste paint. The horizontal stone paint mixer adopts U-shaped appearance design, in which the double-layer spiral belt is used for mixing, and the screw rotation direction is different. When the main shaft rotates, one spiral belt transports the material from left to right, and the other spiral belt transports the material from right to left. The materials are stirred and mixed.

Advantages of spiral mixer machine
1. High stirring efficiency, small floor space. The spiral blade adopts special high – wear alloy.
2. The pan mixer adopts the reducer transmission; the rotation is stable, and the noise is low.
3.Feeding from top and discharging from bottom, which is reasonable structure.
4.The joint surfaces are tightly sealed and run smoothly.

Professional Energy-Saving Lacquer Mixer,Stone Finish Paint Blender , Stone-Like Paint Equipment

Application of spiral mixer machine

The Horizontal Screw Belt Mixer is a new type, high efficiency mixing equipment, are widely used in mixing industry

Our company stone paint mixing machines is easy use and maintains and clean, small occupies, high efficient and long service life; Stone paint mixer machine is specialized in blending the resin emulsion with different gradations of sand particles.

Two discharge ports, fast and clean discharge, mixing screw belt with wall hanging function, mixing cylinder can be turned over, easy for material cleaning, etc.

2. Technical Parameters of spiral mixer machine

Model
2 T
3 T
5 T
10 T
15 T
20 T
30 T
40 T
Main motor power kW
11
15
22
30
30
37
45
55
Reducer
JZQ-350
JZQ-400
JZQ-400
JZQ-500
JZQ-650
JZQ-650
ZSY-280
ZSY-280
Cylinder tilting motor power kW
1.5
1.5
2. 2
3
4
4
5. 5
5. 5
Mixing time
10-15min
Mixing uniformity
97%
Size mm
3000×1100×2200
3200×1200×2200
3600×1400×2400
4500×1700×2500
4700×1800×2500
2500×2100×2700
5800×2300×2950
6300×2500×3200

3. Main Features of spiral mixer machine

Horizontal mixer is rotated by a shaft that added a spiral blade, then adding water to mix while conveying dry ash and other powdery materials, so that the dry ash powder can be humidified equably, which makes the material being humidified do not run dry ash while the water drop can not oozed.

Professional Energy-Saving Lacquer Mixer,Stone Finish Paint Blender , Stone-Like Paint Equipment

How work of fair spiral ribbon mixer

Ribbon mixer consist of a U-shaped horizontal trough and a specially fabricated ribbon agitator.

A ribbon agitator consists of a set of inner and outer helical blades. The outer ribbon moves materials toward the center of the trough,

and the inner ribbon moves the materials toward the outside of the trough. The ribbon also rotates at approx. 50rpm,

thus moving materials both radially and laterally to insure thorough blends in short cycle times.

Ribbon agitators are used for blends that will be between 40 and 70% of the rated capacity of the blender.
