Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash
Specifications
Brand Name :
Fair Machinery
Model Number :
FMZZ-200
Certification :
CE, ISO, SGS
Place of Origin :
Zhengzhou ,China
MOQ :
1 set
Price :
USD2500-24500/set
Payment Terms :
L/C, , T/T, Western Union, MoneyGram, D/A, D/P,Paypal
Supply Ability :
500-1000set/month
Delivery Time :
3-7 work days
Packaging Details :
nuding packing / 1930*625*1210m /500kg
Proudct name :
Dry Powder Mixer Machine
Material :
stainless steel
Mixer Type :
Ribbon
Application :
dry mortar mixer
low noise :
ribbon mixer manufactures
Capacity :
500-5000KG
Description

Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash

Dry Powder Mixer Machine Introduction:

The machine is composed of container, screw paddles and transitional parts; the screw paddle are generally made into 1 layer or 3 layers, the outer screw converge is the material to the centre front two sides, and the inner layer of screw conveys the material to the two sides from the centre, so as to form convention mixing. The cubage can be made into rotundity, so the jacket can be played in reaction and drying.

The advantages of Dry Powder Mixer Machine


1. The circular cylinder body thoroughly achieves no dead cornor, no-residue, mixing uniformity improves over 99%
2. To use high power and low noise cycloid reducer to achieve fast mixing speed, stable rotating, low noise, and long operating life.
3. The fuselage has a viwing port, clean port, and materials addition port so as to clean and maintenance expediently, which is a truly multi-purpose machine.
4. Little investment, small floor area, convenient maintenance and easy to install.
5. It can customise according to clients requirements.

Dry Powder Mixer Machine Technical data

Model

FMZZ-100

FMZZ-200

FMZZ-300

FMZZ-500

FMZZ-1000

FAZZ-2000

FMZZ-3000

FMZZ-5000

Volume M3

0.5

1

2

3

4

5

6

8

Single capacity KG

300

650

1200

1800

2400

3000

3600

4800

Speed

56

46

46

46

46

46

46

46

Power KW

1.5KW

2.2KW

3KW

5.5KW

7.5KW

11KW

15KW

18.5KW

Weight kg

900

2300

3500

4300

6500

7600

8200

11000

Length

1390

1930

2235

2640

3160

3520

3425

4255

Wideth

570

625

760

950

1150

1350

1480

1820

Height

1020

1210

1450

1795

2005

2255

2370

2935

Working progress of Fiar dry mortar mixer:

Firstly, the material is fed intomixer by feeding screw conveyor.In the mixer, there are multiple spiral ribbon inside, the first layer of ribbon pushes materials to the discharging port from charging port,

the second and third layer of ribbon push materials to the charging port from discharging port, then cause convection, therebyforming a more exhaustive mixing.

Why us
Chose happens because of quality, then price, we can give you both.

Additionally, we can also offer professional dry Mortar drum powder mixer machine inquiry, products knowledge train(for agents), smooth goods delivery, excellent customer solution proposals.

Screw 500-5000kg Dry Powder Mixer Machine For Cement Sand Fly Ash

Packaging & Delivery

Packaging Details
WOODEN CASE
Delivery Time
10DAYS AFTER PAYMENT
