Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Metal Steel Brick Wall Mesh , 10cm Width Stucco Wire Mesh 0.9 Kgs / Sqm
Specifications
Brand Name :
Xingtai
Model Number :
BK100
Certification :
IS9001.2000
Place of Origin :
Hebei
MOQ :
500rolls
Payment Terms :
L/C, T/T
Supply Ability :
40000m2/Month
Delivery Time :
10DAY
Packaging Details :
PALTE
Material :
Hot galvanized steel
Thinkness :
0.35mm
Width :
100mm
Length :
1000mm
Packing :
Carton
Description

Brick Wall Mesh Brcikwork Reinforcement Mesh Galvanized Expanded Brick Mesh

Expanded metal reinforcement has numerous applications in all types of building where extra strength and stability is required, as in footings and parapets etc., or to localised stress areas.

Manufactured in coil form from galvanized steel to BS2989 : 1982 Z2 quality, coating G275. Where stainless steel is used it is in accordance with BS 1449: Part 2: 1983. Expanded metal reinforcement is easy to handle, and when laid embedded in the mortar jointing between brickwork or blockwork courses, forms an integral structure of great tensile strength which assists in the resistance to stresses, vibrations and thermal changes.

The range of reinforcement coils satisfies most wall thicknesses, laid on the mortar bed with 25mm clearance to the outside face of the wall and lapped at least 75mm, if joining lengths. The reinforcement is then embedded completely and for most applications, every third course is sufficient.

Galvanized
Steel

Stainless
Steel

Norminal Weight
Kgs/sqm

Roll Size
Width x Length

Recommended
Application

763

763-SS

0.9

65mm x 100m

For 100mm Wall

764

764-SS

0.9

115mm x 100m

For 150mm Wall

765

765-SS

0.9

175mm x 100m

For 200mm Wall

766

766-SS

0.9

225mm x 100m

For 250mm Wall
