Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Specifications
Brand Name :
Dongfeng
Model Number :
2102
Certification :
9001
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T, L/C
Supply Ability :
1500 units per year
Delivery Time :
35 work days
Packaging Details :
In nude
Drive type :
6x6
Cargo Tank Type :
Fence
Tire Size :
12.5R20
Reverse Shift Number :
1
Cab :
Double row
Payload :
5ton
Emission Standard :
Euro 3
Usage :
Personnel/cargo transport
Towing Capacity :
10,000 lbs
Dimension :
7495*2470*2890mm
Transmission Type :
Manual
Fuel Tank Capacity :
100-200L
Engine Capacity :
5.9L
Description

Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck
Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck

Configuration parameter
ModelEQ2102
Chassis brandDongfeng
Drive type6x6
Steering wheelLHD
Overall dimension7613x2470x2985
Wheelbase3475+1250(mm)
Front / Rear suspension1408/1498(mm)
Approach / Departure angle35/34(°)
GVW10850(kg)
Loading capacity3500(kg)
Front/rear axle3.6T/3.6T
Engine modelEQB190-20
Engine brandCUMMINS
Engine power140(kw)/190(hp)
Maximum torque / speed650(N.m)/1700(r/min)
Displacement5.9(L)
Transmission6 speed,manual
Transfer caseMechanical type,two gears
Tire size12.5R20
Number of tire6
Performance parameter
Max speed90(km/h)
Min stable speed3(km/h)
Max climbing gradient60%
Most greatly in slope holding ability40%
Min ground clearance305(mm)
Min turning radius9.4(m)
Maximum cross the vertical obstacle height650(mm)
Maximum cross the trench width700(mm)
Max wading depth1000(mm)


Dongfeng EQ2102G Carrier Truck 6x6 Cargo Truck Off Road Personnel Transport Military Truck

The Dongfeng EQ2102 is a 3.5 tonne capacity troop/cargo carrier truck developed

and built by Dongfeng Motor Corporation and used by the People's Liberation Army

of the People's Republic of China for transport. The truck is based on the Nissan

Diesel Condor CM series via the joint venture between Dongfeng and Nissan.

When in civilian use, this series of trucks uses a variety of different names (from

EQ1101 to EQ5108 depending on the version) but is usually referred to as the

Dongfeng 145. A facelifted version is called the "160".

It entered service in the 1990s to replace the aging CA-30 and the EQ245/EQ2100.
