12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty
12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty
Specifications
Brand Name :
Coreprogram
Model Number :
CVG-12
Place of Origin :
Hefei, Anhui, China
MOQ :
1 set
Price :
Negotiable
Supply Ability :
1000 sets per year
Delivery Time :
15 working days
Packaging Details :
Wooden Box
Payment Terms :
L/C, T/T
Voltage (V/Hz) :
220/50
Description
12 Chute High Capacity Flexible Removal Peanut Cashew Nut Sorting Machine
Product Superiority :
1. Brand new photoelectric design LED light source, More energy-saving, low heat.
2. The light source and the sorting box are set independently to reduce the interference of dust
on the material sorting .
3. Unique bottom exhaust dust removal system, excellent dust removal effect, stable performance
in dusty environment .
4. Easy to learn and operate .
5. Simple optical system design, precise automatic calibration system , well-designed man-machine
interface .

Technical Parameters:

Model Capacity
(t/h)		 Optimized Carryover
(bad:good)		 Sorting Accuracy
(%)		 Power
(Kw)		 Voltage
(V/Hz)

Dimension

L×W×H(mm)

Weight

(kg)
XCS80 0.8-1.2 >20:1 >99.9 0.5-0.8 220/50 967*1553*1784 286
CVG-5 3-5 >20:1 >99.9 3.3 220/50 2617*2077*1795 1532
CVG-6 3.5-6 >20:1 >99.9 4.2 220/50 2955*2077*1795 1752
CVG-7 3.5-8 >20:1 >99.9 5.0 220/50 3293*2077*1795 1910
CVG-8 4-9 >20:1 >99.9 6.0 220/50 3641*2077*1795 2170
CVG-10 5-12 >20:1 >99.9 7.05 220/50 4317*2077*1795 2520
CVG-12 6-13 >20:1 >99.9 8.3 220/50 4993*2077*1795 2960

Note: Due to different raw materials and different impurities ratio , parameters above will
vary to some extent ,which are references for you choosing a suitable model.

Working Schematic :

12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty

From the schematic ,we can learn that when the materials enter the chute ,the sensor will recognize the shape and color of materials, if there are some specked ,splitted ,rotten and other defects,the ejector system will release compressed air to change the path of rejected materials with defects into rejected hole . The accepted materials will come out from the accepted hole .

Sorting Case :
Example of Macadamia and Peanuts Sorting
12 Chute Peanut Color Sorter / Cashew Colour Sorting Machine 1 year Warranty
Accepted Rejected Accepted Rejected

Our Service:

• One year quality warranty for the machine and spare parts.
• Engineers service for installation overseas.
• Whole-life after-sales service and free consultation.
• Customized requirements available.
• Technician guide at the site.
• 24 Hrs online service.
