Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box
Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box
Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box
Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box
Specifications
Brand Name :
Longxingsheng
Model Number :
LS-450plus
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
15sets/month
Delivery Time :
7-15 work days
Packaging Details :
With paper,film and by wooden crate.
Product name :
Multi-Function Packaging Machine For Paper Box Packing & Hard Cover & Cellphone Box
Type :
Multi-Function packaging machine
Working speed :
15-35pcs/min
Application :
Box positioning and paper gluing
Dimension(L*W*H): :
L5980*W3185*H2104
Weight of machine :
2141kg
Description

Multi-Function Box Packaging Positioning Machine For Paper Box Packing & Book Cover & Cellphone Box

Introduction:

LS-450plus is a multi-function visual positioning machine. It is able to positioning the rigid box and hardcover. also can do paper lining, one machine with many functions, and the working model is able to be changed by one button. It has higher flexibility feeder ,anti leaking & visual

positioning (including:YAMAHA robotic arm & two HD camera)
Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box

Equipped with dual cameras, the cameras are located on both sides of the central position of the conveyor belt. The camera position has been calibrated before leaving the factory. If there is any deviation, you can adjust the camera position by adjusting the upper camera "mounting plate". After the camera takes a picture, the system recognizes the color difference of the photo for positioning. If the surface paper and the surface paper conveyor belt are similar in color, it can be solved by changing the belt color.

Main features:

1. High speed, Max speed is 42 pcs/min.
2. Easy adjustmen, the min setting time of change model is 7 minutes.
3. No-move camera when change sizes.
4. Double Germany Basler cameras (ten million pixels).
5. Dual feeding system, one button change box feeding to hardcover feeding system.

6. Panasonic Servo motor feeding system..

Advantages:
  • Flexible
Can connect with four sides wrapping machine to make the hardcover
Can work with box wrapping machine to make rigid box
Can make special box, such as slant side box (videos are available)
  • High speed
With 2 sets LS-F7 box wrapping machine, the speed of machine can make around 131000 pcs per day
  • Save setting time
Only need 7 minutes when change product mode
One bottom to change case to box
No stop working when change different size, because one F6 for presetting and another one can keep working
Optional function:
  1. Glue Viscosity Device : Automatic detecting the hot melt glue thickness.
  2. Air Operated Double Diaphragm Pump: Applied in white glue pumping.
  3. Bottom sucker hardcover feeding device: Special design for feeding hardcover, to avoid scraping hardcover.

Specifications of LS-450plus:
Type LS-450plus
Paper size (Max) L800*W600mm
Paper size (Min) L135*W100mm
Max box size L600*W400*H120mm
Min box size L80*W65*H15mm
Book cover (Max) L750*W450mm
Book cover (Min) L150*W100mm
Paper thickness 100-350g/㎡
Paper stacking height 280mm
Motor power / voltage 7.5kw/380v, 3 phase
Heating power 8kw/380v, 3 phase
Air supply 10L/min 0.6Mpa
Working speed 15-45 sheets/min
Machine dimension L5980*W3180*H2100mm
Weight of machine 2100kg





































Company profile:
Paper Box Multi Function Packaging Machine For Hard Cover / Cellphone Box
Dongguan Longxingjian Intelligent Equipment Co.,Ltd

Dongguan Longxingjian Intelligent Equipment Co., Ltd, our company was established in 2006-01-26. The company address is located in Room 102, Building 2, No. 3 Bajiaowo Chuangye Road, Wanjiang Street, Dongguan City, Guangdong Province. Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of quality first, customer first and credit-based; Since the establishment of the company and always do our best to satisfy potential needsof our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation,since the trend of economic globalization has developed with anirresistible force.Welcome to communicate and negotiate at any time.

Our service

Pre-sale service:

* Inquiry and consulting support.
* Sample testing support.
* Factory visit.

After-sale service:

* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* Free machine parts replacement during warranty.
* Whole life of machine service.
