Specifications
Brand Name :
Longxingsheng
Model Number :
LS-450plus
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
15sets/month
Delivery Time :
7-15 work days
Packaging Details :
With paper,film and by wooden crate.
Product name :
LS-450plus High-End Perfume Box Gluing And Positioning Machine For Rigid Box
Type :
Multi-Function box gluing machine
Working speed :
15-39 pcs/min
Application :
Case positioning and gluing machine
Dimension(L*W*H): :
L5980*W3185*H2104
Weight of machine :
2141kg
Power :
380V
Positioning accuracy :
±0.1mm
Description

Automatic High-Precision, Simple-To-Setup Vision Positioning Machine

Introduction:


LS-450plus is a multi-functional visual positioning machine. Realizes the positioning of hard boxes and hard covers. It can also be used as a paper lining, allowing multiple uses in one machine, and working modes can be switched with one click. Visual positioning system can be upgraded. Additionally, it is possible to upgrade to an automatic line in the future if required.

Hardcover feeding device:

1. The "motor forward and reverse button" controls the forward and reverse rotation of the motor to drive the "belt" rotation, thereby controlling the forward and reverse rotation of the "gray board feed knife bar" to meet the purpose of feeding. will be achieved. hardcover book.


2. The function of the “blade” is to drive the hardcover book into a position that the robot arm can precisely position. Each "intermediate pallet" is usually equipped with a "blade", the position of which can be adjusted by loosening a countersunk screw.


3. You can attach a "side baffle" to the "side tray" that restricts the left and right movement of the gray board. When adjusting the "side pallet", you can turn the handle to bring both sides of the "side baffle" closer to the gray board. Four "push rods" are assembled on four "intermediate pallets". The "middle push plate" can be adjusted by loosening the "flat head screw" and moving the "push rod" to match the actual width of the hardcover book, and the "flat head screw" will move to the appropriate position in the width direction. hardcover book. "T slot rod".


4. The function of the "stop" is to fix the gray board in place and prevent it from backing up. Loosen the screw that fixes the "push plate", move the position of the "push plate", and then tighten the screw to complete the "stopping".​

Automatic High-Precision, Simple-To-Setup Vision Positioning Machine

Main features:

1. High speed, maximum speed is 42 pieces/min.
2. Easy to adjust, minimum setting time for mold change is 7 minutes.
3. Do not move the camera when resizing.
4. Dual German Basler cameras (10 million pixels).
5. Dual paper feeding system, one click box change and paper feeding to hardcover paper feeding system.
6. Panasonic servo motor power supply system.
Advantages:
  • Flexible
Can connect with four sides wrapping machine to make the hardcover
Can work with box wrapping machine to make rigid box
Can make special box, such as slant side box (videos are available)
  • High speed
With 2 sets LS-F7 box wrapping machine, the speed of machine can make around 131000 pcs per day
  • Save setting time
Only need 7 minutes when change product mode
One bottom to change case to box
No stop working when change different size, because one F6 for presetting and another one can keep working
Optional function:

1.Adhesive viscosity measuring device: Automatically detects the thickness of hot melt adhesives.


2.Pneumatic double diaphragm pump: used for pumping white glue.


3.Bottom suction cup hardcover paper feeder: Specially designed for hardcover paper feeding to avoid scratching the hardcover.

Specifications of LS-450plus:
Type LS-450plus
Paper size (Max) L800*W600mm
Paper size (Min) L135*W100mm
Max box size L600*W400*H120mm
Min box size L80*W65*H15mm
Book cover (Max) L750*W450mm
Book cover (Min) L150*W100mm
Paper thickness 100-350g/㎡
Paper stacking height 280mm
Motor power / voltage 7.5kw/380v, 3 phase
Heating power 8kw/380v, 3 phase
Air supply 10L/min 0.6Mpa
Working speed 15-45 sheets/min
Machine dimension L5980*W3180*H2100mm
Weight of machine 2100kg





































Company profile:
Automatic High-Precision, Simple-To-Setup Vision Positioning Machine
Dongguan Longxingjian Intelligent Equipment Co.,Ltd

We are located in world manufacturer city----Dongguan City, Guangdong Province. The former compay name is Dongguan Longxingsheng Machinery Co.,Ltd.

We have independent R&D department. Up to now, We have got more than 20 patents including pratice patents, appearance patents and technology-based patents. We have been specialized in post-press machinery's research, development, manufacturing and selling for more than 13 years. Grooving machine series and rigid box forming series are our main products.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.

Our service:

Automatic High-Precision, Simple-To-Setup Vision Positioning Machine

Pre-sale service:

* Inquiry and consulting support.
* Sample testing support.
* Factory visit.
* Details communicating

After-sale service:

* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* Free machine parts replacement during warranty.
* Whole life of machine service.
