Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Specifications
Brand Name :
Longxingsheng
Model Number :
LS-1246D
Certification :
CE/ISO-9001
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 Sets per month
Delivery Time :
7-30 workdays
Packaging Details :
with film, paper and wooden crates
Products Name :
Automatic Smart High Speed Rigid Lid And Base Box Making Machine With Visual Positioning
Box Length :
97-600mm
Box Width :
87-400mm
Box Height :
27-120mm
Edge folding size :
10-60mm
Turn in depth :
15-60mm
Positioning accuracy :
0.15mm
Tape :
plastic/paper/Kraft tape
Glue :
Animal glue and White glue
Description

Automatic Smart High Speed Rigid Lid And Base Box Making Machine With Visual Positioning

LS-1246D is an upgrade model of LS-300A, as LS-300A has a high speed in 30 pcs/min. But the disadvantage is setting not smart. As manual setting will required around 90-120 minutes. But the LS-1246D has the setting time in 45-60 minutes.

With the developing of rigid box production, more customer are looking for an automatic rigid box making machine with high speed and intelligent setting. So that the worker can focus on the rigid box production not in machines itself.

The max box length is 600mm, max width is 400mm, Max height is 120mm. Whole line has applied the visual positioning technology in rigid box making. Ensure its high working speed and accuracy, Whole working speed can be adjusted in one button. The intelligent setting has ensured it can change new size in the shortest time.

Specs of autoamtic smart rigid box making machine
Type LS-1246D
Paper size(max) L800*W600mm
paper size(min) L135*W100mm
Max cardboard size L760*W560mm
Min cardboard size L120*W100mm
Box size(length) L100-600mm
Box size(width) W60-400mm
Box size(height) H15-120mm
Paper thickness 80-350g/m2
Cardboard thickness 0.8-3mm
Edge folding size 10-90mm
Turn in depth 15-80mm
Working speed 15-45 pcs/min
Motor power 13kw/380v 3phase
Heating power 8kw
Air pressure 40L/min 0.8MPa
Weight of machine 4300kg
Machine dimension L6600*W4200*H3000mm

Machine advantages
Quickly job setting
No need to move camera for size changing, quick job changing
Make high-end boxes
Special pick up and wrapping system
Storage(memory) function for sizes setting
Suitable for changeable orders
Such as 10,000 pcs for one order
Main features:
1. Automatic setting function.
2. Storage function for the positioning part, easy to adjustment
3. Pick up box system, can avoid to scraping cover paper, suitable for making high-end boxes
4. Mitsubishi servo motor
5. Panasonic PLC
Price vary with raw material cost, please contact our sales for latest prices.
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm Machine setting time: Short in 45 minutes
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Intelligent setting page
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Machine parts
About our company
Smart Rigid Lid Base Industrial Packing Box Making Machine 0.15mm
Dongguan Longxingjian Intellighent Equipment Co.,Ltd is located in the famousmanufacturing city - Dongguan City,China. Our former company name is Dongguan Longxingsheng machinery CO.,Ltd. We are the leader & professional manufacturer of Automatic/semi-auto rigid box maker which is for for making varies rigidbox ,such as cardboard boxes, luxury boxes, jewelry boxes,calendar, gift boxes, sweet boxes,shoes boxes, watch boxes, mobile phone boxes, high-end boxes and etc. Our company has been established since 2006.With years experience of machinery's development,manufacturing & selling,our products are with high quality & enjoy very good reputation in global market,especially in Europe,Asia,Mid-east and America. We are much appreciated & treasure our customers' trusting & supporting, and we will always keeping providing high quality products & good after-sales service to you.
Our advantages
Certificates: ISO9001-2008, Quality management system, CE certificate.
Mission & Vision: Provide smart modular for packaging.
Products scope: Automatic rigid box making machine. V grooving machine. Visual positioning machine. Rigid box former. Corner pasting machine. Gluing machine and other machinery.
Market positioning: Middle and high-end market
Space of Dongguan Fty:10598m2
Major market: America, Europe, Asia, Mid-east.
