Specifications
Brand Name :
SenYan
Model Number :
FR4 PCB
Certification :
ISO14001,ISO13485,ISO9001,IATF16949
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100000pcs
Delivery Time :
1-30days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Name :
FR4 PCB
Solder mask :
Green
Silk Screen :
White
Surface Technics: :
HASL-F
Max panel size :
32＂×20＂（800mm×508mm）
Layer count :
2~18
Pcb standard :
IPC-A-610 D/IPC-III Standard
Type :
pcb/printed circuit board/oem pcb
Description

FR4 PCB One Stop Electronic Design Pcb Manufacturing And Pcb Assembly


Senyan is China PCB assembly manufacturer ,who offers complete PCB services in Shenzhen , Senyan‘s capable of providing turn-key and partial turn-key printed circuit board assembly services.

For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.


Flexible Volume Assembly Alternatives:
Prototype PCB Assembly
Low-Volume, High Mix PCB Assembly
High-Volume PCB Assembly
Consigned & Partial PCB Assembly
Full Turnkey PCB Assembly
Cable & Wire Harness Assembly
Box Build Assembly Services

Our Services & Strength

>Factory workshop area of 4000 square meters
>Employees:200, including 10 senior technicians
>OEM one stop service :from pcba to finished products
>6 SMD machine lines, 6 million points capacity per day
>4 DIP lines and 25K PCBAs per day.
>4 assembly lines and 3-7K finished products per day.
We help
Your Troubles
Our Strategy
Lack of engineering experience
Various unexpected problems, causing the project to fail
Rich engineering experience: Bom Engineer/ Product Engineer/ Technical Engineer /Purchasing Engineer.Eliminate Problems and pitfalls at the design stage
Coordinating multiple suppliers
Insufficient time and energy
PCB Assembly and welding factory, Component procurement team,Function Test , Finished Product Assembly. Provide one-stop service, save time and worry
Product quality control
High hardware trial and error cost
Rigorous process and strong strength
We have established a standardized and rigorous process and system to effectively reduce quality problems
Traders do not have physical factories
The quality is not guaranteed, Documents easy to disclose
Own teams and factory, the delivery time is more controllable
Hard delivery guarantee
The market can't wait
Complete Organizational Structure: Project Department, Engineering Department, Purchasing Department, Quality Department,
Production Department, Etc.

One Stop Electronic Circuit Board Manufacturers HASL FR4

One Stop Electronic Circuit Board Manufacturers HASL FR4
One Stop Electronic Circuit Board Manufacturers HASL FR4
SMT Manufacturing Capability
SMT Manufacturing Capability
Item
Manufacturing Capability in process
Manufacturing Method
Production size(Min/Max)
50×50mm / 500×500mm
Production board thickness
0.2 ～ 4mm
Printing solder paste
Support method
Magnetism fixture, vacuo platform
Clamping method
Sticking up by vacuo, clamping on both sides ,flexible clamping with sheet, flexible clamping with thick board
Cleaning Method of printing solder paste
Dry method+ wetting method+ Vacuo method
Accuracy of printing
±0.025mm
SPI
Repeated accuracy of volume
<1% at 3σ
Mounting component
Components size
0603(Option) L75mm Connector
Pitch
0.15mm
Repeated accuracy
±0.01mm
AOI
FOV size
61×45mm
Test speed
9150mm²/Sec
3D X-ray
Shootingangle
0-45
Rigid RPCB Manufacturing Capability
Rigid RPCB Manufacturing Capability
Item
RPCB
HDI
minimum linewidth/linespacing
3MIL/3MIL(0.075mm)
2MIL/2MIL(0.05MM)
minimum hole diameter
6MIL(0.15MM)
6MIL(0.15MM)
minimum solder resist opening (single-side)
1.5MIL(0.0375MM)
1.2MIL(0.03MM)
minimum solder resist bridge
3MIL(0.075MM)
2.2MIL(0.055MM)
maximum aspect Ratio (thickness/hole diameter)
10:1
8:1
impedance control accuracy
+/-8%
+/-8%
finished thickness
0.3-3.2MM
0.2-3.2MM
maximum board size
630MM*620MM
620MM*544MM
maximum finished copper thickness
6OZ(210UM)
2OZ(70UM)
minimum board thickness
6MIL(0.15MM)
3MIL(0.076MM)
maximum layer
14层
12层
Surface treatment
HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag
Immersion Gold,OSP,selectiveimmersion gold,
carbon print
Min/max laser hole size
/
3MIL / 9.8MIL
laser hole size tolerance
/
10%
Our Services
One Stop Electronic Circuit Board Manufacturers HASL FR4

One Stop Electronic Circuit Board Manufacturers HASL FR4

One Stop Electronic Circuit Board Manufacturers HASL FR4

Q1.What is needed for quotation?

A: PCB : Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)
PCBA: PCB information, BOM, (Testing documents...)

Q2. What file formats do you accept for production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

Q3. Are my files safe?
A: Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.

Q4. MOQ?
A: There is no MOQ in Senyan.We are able to handle Small as well as large volume production with flexibility.

Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

Q6. Do you accept process materials supplied by clients?

A Yes, we can provide component source, and we also accept component from client
