HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
Specifications
Brand Name :
RION
Model Number :
HCA520/HCA528
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
335 USD/pcs
Payment Terms :
T/T, PayPal
Supply Ability :
500 pcs/month
Delivery Time :
7 word days
Packaging Details :
carton
Measure range :
±30°
Measure axis :
Pitch and roll
Resolution :
0.001°
Measure accuracy :
0.005°
Long term stability :
0.01°
Zero Temp.coefficient :
±0.002°/℃
size :
L90 × W59 × H34mm
Description

Aluminum Case High Accuracy Voltage Inclinometer Vehicle leveling Slope Meter Tilt Monitoring Sensor

▶ TECHNICAL DATA

HCA520T CONDITION PARAMETERS UNIT
Measure range ±10 ±30 °
Zero output 0° output 2.5 2.5 V
Measure axis X / XY X / XY AXIS
Resolution 0.001 0.001 °
Measure accuracy @25℃ 0.005 0.01 °
Zero Temp.coefficient -40～85℃ ±0.0005 ±0.0008 °/℃
Sensitivity temp-coeffi -40～85℃ ≤100 ≤100 ppm/℃
Power on time 0.5 0.5 S
Response time 0.02 0.02 s
Response frequency 20Hz
output signal 0~5V
EMC According to EN61000 and GBT17626
MTBF ≥50000hours/times
Insulation Resistance ≥100MΩ
Shockproof 100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration 10grms,10～1000Hz
Protection grade IP67
Cables Standard 1 meter length, wear-resistant, wide temperature, shielded cable 4 * 0.4mm2 aviation connector
Weight 190g(without cable)

* This parameter only list ± 10 °, ± 30 ° series for reference. For other measurement ranges, please refer to the nearest neighbor parameter.

▶ FEATURES

★ Single / dual axis inclination measurement

★ Range ± 1～± 90° optional

★ Accuracy: Refer to technical data

★ Wide voltage input 9～36V

★ Output mode 0～5V

★ Wide temperature operation -40 ℃～+ 85 ℃

★ IP67 protection

★ High vibration resistance> 2000g

★ High resolution 0.001 °

★ Small size L90 × W59 × H34mm

▶ APPLICATION

★ Equipment vehicle leveling

★ Bridge and Dam monitoring

★ High-altitude platform safety protection

★ Angle control of medical equipment

★ Attitude navigation of underground drilling rig

★ Leveling of railway gauge and gauge

★ Direction measurement based on tilt angle

★ Tilt monitoring of geological equipment

★ Mining machinery, oil drilling equipment

★ Equipment level control

★ Alignment control , curve control

★ Pitch angle measurement of directional satellite communication antenna

ELECTRICAL CONNECTION

SINGLE AXIS CABLE WIRE CONNECTION

Wire Color function RED WHITE GREEN BLACK GRAY

DC9~36V

Power supply positive

Out X

X axis output voltage

 NC

GND

Power negative

 Signal ground

HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter

HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter

HCA520 Voltage High Accuracy Inclinometer , Vehicle Leveling Slope Meter
