Specifications
Model Number :
AKF390
Place of Origin :
Guangdong, China
Brand Name :
RION
Packaging Details :
1pcs accelerometer in each inner box , 80pcs /ctn
Price :
$236.00/Pieces
MOQ :
1
Payment Terms :
T/T
Supply Ability :
500/month
Delivery Time :
1 weeks for samples
Certification :
CE
Usage :
VIBRATION SENSOR
Range Rs=100 :
±40g
Threshold (Resolution) :
1mg
Deviation temp. coefficient :
0.01%/℃
Frequency response :
500Hz
Bandwidth (3DB) :
1000Hz
Resonance frequency :
2.4kHz
Noise density :
21 μg/√Hz
Description

MAIN FEATURE

★ Three axes (X, Y, Z)

★ Output signal: RS232; RS485; TTL

★ Power supply voltage: 9-36V

★ Impact resistance: 2000G

★ Working temperature: -40°C ~ +85°C

★ Storage temperature: -40°C ~ +85°C

★ Size: L34.3×W34.3×H38.5mm

★ Excellent deviation stability, good environmental performance (shock, vibration and temperature)

APPLICATION

★ Medical equipment

★ Bridge

★ Automobile

★ Road roller

★ Wind power generation

★ Large machinery, engines

★ Low-frequency vibration and automatic monitoring

★ Traffic system monitoring, roadbed analysis and high-speed railway fault detection


Product Description

voltage output 0~5v output accelerometer

PRODUCT INTRODUCTION

The AKF390 triaxial accelerometer is a voltage output type accelerometer independently developed and produced by RION Technology, which can be used in many fields such as vibration test and impact test. The product adopts analog voltage output, different address codes can be set, and multiple sensors are connected in series for a long distance, which is convenient for multi-point measurement and data analysis. AKF390 is a single crystal silicon capacitive sensor, which consists of a silicon chip processed by micro-machines, a low-power ASIC for signal adjustment, a microprocessor for storing compensation values, and a temperature sensor. This product has low power consumption, calibrated, sturdy structure and stable output. The new electronic configuration provides solid-state power for reset and comprehensive protection from over-voltage. The products have the characteristics of sturdy structure, low power consumption, excellent deviation stability, etc., to ensure the reliability of product output.
