Specifications
Model Number :
DMI850
Place of Origin :
Guangdong, China
Brand Name :
RION
Packaging Details :
1pcs/box,10pcs/ctn
Supply Ability :
300 Set/Sets per Month
Price :
$2345/Pieces
Certification :
CE
MOQ :
1
Payment Terms :
T/T, Paypal
Delivery Time :
10 days
Usage :
Magnetic Sensor
Theory :
fluxgate
Output :
Digital Sensor
Material :
metal
Size :
L150*W150*H47mm
Weight :
1200g
Waterproof :
IP54
Working temp. :
-10~70 celsius degree
Power supply :
3.7v rechargeable lithium battery
Data Output :
USB1.1
Shock impact :
10grms,10-100Hz
Port :
Shenzhen
Description

Super Precise Digital Inclinometer, 0.001 Accuracy Inclinometer, Alarm Inclinometer

Product Description

*Single /Dual axis Digital Inclinometer

*Developed by RION company based on high precise angle measurement platform

*Built-in 32 bit microprocessor and collocation 32 bit high precision analog-to-digital converter

*Can highly subdivision sampling

*Highest level accuracy of 0.001 degrees

*Resolution 0.0002 degrees

*Built-in large capacity rechargeable battery

*Batterry continuous working time up to 12 hours

*Product integrates USB serial interface

*Real-time transmission of current measurement results

*Read the measurement data level of internal storage

*Data playback and analysis can be carried out on site chart

*Best instrument and measurement of high precision adjustable platform

Key Features

Best accuracy:<0.001°
Repeatability:0.002°
Angle resolution:0.0002°
Maximum measuring range:±30°
User can set the alarm value by himself
Data store function
Absolute/Relative measurement can switch
Both sides and bottom can measure
Double benchmark strong magnet installation
Working Temperature : -10°~ +70℃
Auto-angle interleaved compensation function
Auto temperature drift compensation
User can calibrate ZERO by himself
Built-in rechargeable industry batteries
Night vision fours colors screen
IP54 protection class
°/mm/m Dual units switch function
Filter frequency optional
Three kinds of measurement mode selectable (radian, angle, mm)

Application

Building construction
Automobile four-wheel testing
Road slope
Machinery installation
Piping installation
Industrial platform
Turntable testing
Pan unit angle detection
Production jig
Medical instruments

Specification

DMI850 PARAMETER unit
Measurement Range ±30 °
Measuring Axis Single-axis
Best Accuracy <0.002 (<5°),<0.003 (5°-30°) °(RMS)
Resolution 0.0005 °
Measurement Mode Two modes can be set: degree, mm / m /
Lcd 64 color true color luminous display /
Lcd Visible Size L60*W45 mm
Operating Temperature -10°~ +70℃ °/℃
Working Humidity 85 %RH
Power Supply 2A No.5 battery /
Battery Continuous Working Time 6 h
Anti-Vibration 10g @ 11ms, triaxial and same (half sine wave) /
Impact Resistance 10grms,10~100Hz /
Weight 1200 g
Protect Class IP54 /
Material Anodizing of aluminum alloy /
Size L140*W140*H45mm mm

Inclinometer series with different accuracy and resolution

Resolution: 0.01 Resolution: 0.001 Resolution: 0.0005

CE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle MeterCE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle MeterCE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle Meter

Inclinometer with built-in display

Resolution: 0.01° Resolution: 0.001°

CE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle MeterCE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle Meter

please click the picture if any of them make you interested

CE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle Meter
CE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle Meter
CE Alarm High Accuracy Digital Inclinometer 0.001 Deg IP54 Angle Meter

Packaging & Shipping

Packaging: carton with sponge
Delivery time: within 7 business days for common order after we receive the full payment
Shipping time: 3-5 work days by DHL/UPS/FEDEX/TNT; 5-7 work days by EMS.
