Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
Specifications
Brand Name :
Deye
Model Number :
SUN-3.6K-SG03LP1-EU
Certification :
IEC/EN 61000-6-1/2/3/4
Place of Origin :
China
MOQ :
1
Price :
US$+2600-2800+piece
Payment Terms :
T/T
Supply Ability :
10000 pieces month
Delivery Time :
10-15workday
Packaging Details :
Each product is individually packaged in a carton or packaged according to your requirements.
Input Voltage :
150-425V
Output Voltage :
220/230Vac
Output Current :
54.5/52.2A
Output Frequency :
50/60Hz
Output Type :
Single
Size :
464*282*763mm
Inverter Efficiency :
97.6%
Warranty :
5 Years
Weight :
48.5kg
Application :
Solar Power System Home
Rated power :
12kw
Type :
DC/AC Inverters
Description

12KW Cheap price Deye Hybrid Solar Inverter 12KW SUN-12K-SG01LP1-EU AC 230V Single Phase for Home Solar System

Model SUN-12K-SG01LP1-E SUN-14K-SG01LP1-
EU		 SUN-16K-SGO1LP1-EU
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range (V) 40~60V
Max. Charging Current (A) 220A 250A 290A
Max. Discharging Current (A) 220A 250A 290A
UPS Power (W) 10000 12000 14000
Charging Curve 3 Stages / Equalization
External Temperature Sensor Yes
Charging Strategy for Li-lon
Battery		 Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W) 15600 18200 20800
Max. DC Input Voltage (V) 500
Start-up Voltage (V) 125
MPPT Range (V) 150~425V
Rated DC Input Voltage (V) 370
PV Input Current (A) 26+26+26
Max. PV ISC (A) 44+44+44
No.of MPPT Trackers 3
No.of Strings Per MPPT
Tracker		 2
AC Output Data
Rated AC OutputPower (W) 1200W 1400W 1600W
AC Output Rated Current (A) 52.2 60.9 69.5
Max. Continuous AC
Passthrough (A)		 100
Peak Power (off grid) 2 times of rated power, 5 S
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50/60Hz; L/N/PE 220/230Vac (single phase)
Grid Type Single Phase
DC injection current (mA) <0.5% 1n
Efficiency
Max. Efficiency 97.60%
Euro Efficiency 96.50%
MPPT Efficiency 99.90%
Certifications and Standards
Grid Regulation CEI 0-21, VDE-AR-N 4105,NRS 097,IEC 62116,IEC 61727,G99,G98
VDE 0126-1-1.RD 1699,C10-11
Safety EMC/Standard EC/EN 61000-6-1/2/3/4,IEC/EN 62109-1,IEC/EN 62109-2
General Data
Operating Temperature Range
(℃)		 45~60°℃,>45°℃ Derating
Cooling Smart cooling
Noise (dB) <30 dB
Communication with BMS RS485;CAN
Weight (kg) 48.5
Size(mm) 464Wx798.4H×300D
Protection Degree IP65
nstallation Style Wall-mounted
Warranty 5 years

Deye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230VDeye High Voltage Hybrid Inverter SUN-12K-SG01LP1-EU AC 230V
