Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
Specifications
Brand Name :
Deye
Model Number :
SUN-6K-SG04LP3-EU
Certification :
CE ISO TUV
Place of Origin :
China
MOQ :
1
Price :
US$+1828-2028+piece
Payment Terms :
T/T
Supply Ability :
10000 pieces month
Delivery Time :
10-15workday
Packaging Details :
Each product is individually packaged in a carton or packaged according to your requirements.
Input Voltage :
550V(160V~800V)
Output Voltage :
220/380Vac,230/400Vac
Output Current :
7.6-18.2A
Output Frequency :
50/60Hz
Output Type :
Single
Size :
422*279*699.3 mm
Inverter Efficiency :
99%
Warranty :
5 Years
Weight :
33.6KG
Application :
Solar Power System Home
Rated power :
6kW
Type :
DC/AC Inverters
Certificate :
CE ISO TUV
Description

Factory Direct Supply SUN-6K-SG04LP3-EU Deye Hybrid Inverter Solar Hybrid Inverter

Model SUN-5K-
SG04LP3-EU		 SUN-6K-
SG04LP3-EU		 SUN-8K-
SG04LP3-EU		 SUN-10K-
SG04LP3-EU		 SUN-12K-
SG04LP3-EU
Bamery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage
Range (V)		 40~60V
Max. Charging
Current (A)		 120A 150A 190A 210A 240A
Max. Discharging
Current (A)		 120A 150A 190A 210A 240A
Charging Curve 3 Stages /Equalization
Extemal
Temperature
Sensor		 Yes
Charging Strategy
for Li-lon Battery		 Seli-adaption to BMS
PVStringInput Data
Max. DC Input
Power (W)		 6500W 7800W 10400W 13000W 15600W
Rated PV Input
Voltage (V)		 550V(160V～800V)
Start-up Voltage
(V)		 160V
MPPT Range (V) 200V-650V
Full Load DC
Voltage Range (V)		 350V-650V
PV Input Current
(A)		 13A+13A 26A+13A
Max. PV ISC (A) 17A+17A 34A+17A
Number of MPPT/
Strings per MPPT		 2/1 2/2+1
AC Output Data
Rated AC Output
and UPS Power
(W)		 5000W 6000W 8000W 10000W 12000W
Max.AC Output
Power (W)		 5500W 6600W 8800W 11000W 13200W
Peak Power (off
grid)		 2 times of rated power, 10 S
AC Output Rated
Current (A)		 7.6/7.2 9.1/8.7 12.1/11.6 15.2/14.5 18.2/17.4
Max. AC Current
(A)		 11.4/10.9 13.6/13 18.2/17.4 22.7/21.7 27.3/26.1
Max. Continuous
AC Passthrough
(A)		 45A
Output Frequency
and Voltage		 50/60Hz;3L/N/PE 220/380Vac,230/400Vac
Grid Type Three Phase
Current Harmonic
Distortion		 THD<3%(Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
Euro Efficiency 97.00%
MPPT Efficiency 99.90%
Protection
PV Input Lightning
Protection		 Integrated
Anti-islanding
Protection		 Integrated
py string Input
Reverse Polarity
Protection		 Integrated
Insulation Resistor
Detection		 Integrated
Residual Current
Monitoring Unit		 Integrated
Output Over
Current Protection		 Integrated
Output Shorted
Protection		 Integrated
Output Over
Voltage Protection		 Integrated
Surge protection DC TypeⅡI/AC Type Ⅲ
Certifications and Standards
Grid Regulation CEI 0-21, VDE-AR-N 4105 , NRS 097 ,IEC 621 16, IEC 61727,G99,G98,VDE 0126-1-1,RD
1699,C10-11
Safety EMC/
Standard		 IEC/EN 61000-6-1/2/3/4,IEC/EN 62109-1,IEC/EN 62109-2
General Data
Operating
Temperature
Range (°C		 -45~60°C,>45°℃ Derating
Cooling Smart cooling
Noise (dB) <45 dB
Communication
with BMS		 RS485; CAN
Weight (kg) 33.6
Size (mm) 422W×699.3H×279D
Protection Degree IP65
Installation Style Wall-mounted
Warranty 5 years

Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65

Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65Deye Sun 6K Low Voltage Hybrid Inverter Wall Mounted IP65
