SATV/SMATV NORSAT C Band LNB PLL 3000 lnb
SATV/SMATV NORSAT C Band LNB PLL 3000 lnb
Specifications
Brand Name :
RITEL or OEM
Model Number :
SATV/SMATV NORSAT C Band LNB PLL 3000 lnb
Certification :
CE, UL, ISO9001
Place of Origin :
CHINA
MOQ :
1PCS
Price :
$10.00~$100.00/PC
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
20000pcs per months
Delivery Time :
Depends on quantity
Packaging Details :
Carton, box
Description
SATV/SMATV NORSAT C Band LNB PLL 3000 lnb

Description

Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs.

Norsat LNBs.

Features:

The industry’s best LO (Local Oscillator) stability

High performance for any application

Excellent availability and short lead times

Designation Version

Frequency Stability

Noise coefficient/temperature
C-band DRO – 8000series
C DRO 8115 ±100 KHz 15°K
C DRO 8215 ±250 KHz 15°K
C DRO 8515 ±500 KHz 15°K
C-band PLL – 3000series
C PLL 3120 ±5 KHz 20°K
C PLL 3220 ±10 KHz 20°K
C PLL 3530 ±25 KHz 30°K
C-band Ext Ref – 3000X series
C PLL 3025X - 25°K
C PLL 3030X - 30°K
Ku-band DRO – 2000Bseries
Ku DRO 2708B ±750 KHz 0.8 dB
Ku-band DRO – 4000Bseries
Ku DRO 4108B ±150 KHz 0.8 dB
Ku DRO 4208B ±250 KHz 0.8 dB
Ku DRO 4508B ±500 KHz 0.8 dB
Ku-band PLL – 1000HBseries
Ku PLL 1508HB ±5 KHz 0.8 dB
Ku PLL 1108HB ±10 KHz 0.8 dB
Ku PLL 1208HB ±25 KHz 0.8 dB
Ku-band Ext Ref – 1000XB series
Ku Ext Ref 1009XB - 0.9 dB
Ku Ext Ref 1010XB - 1.0 dB

Specification:

Noise temperature: 20K to 30K depending on model number

L.O. stability: ±2 kHz to ±25 kHz depending on model number

(over temperature excl offset)

Phase noise: -80 dBc/Hz at 1kHz

(SSB) -85 dBc/Hz at 10kHz
-95 dBc/Hz at 100kHz

Input VSWR: 2.2 : 1

Output VSW : 2.2 : 1


Conversion gain: 62 dB
Output P1dB: 9 dBm
Power requirements: +12 to +24 V supplied through
center conductor of IF cable
Current drain: 250 mA
Input Waveguide: CPR229G
Dimensions: 144 (L) x 70 (W) x 98 (H) mm
(5.7 x 2.8 x 3.9 in)
Weight: 500 g / 17.6 oz
Temperature Range: -40C to +60C
Relative Humidity: 0 - 100% condensing

Input frequency (GHz): 3.40 to 4.20
L.O. frequency (GHz): 5.15
Output frequency (MHz): 950 to 1750
