EMI Gasket Right Angle 1000 Base T RJ45 Connector 8P8C PCB Jack Socket

Description:

  • Model number: MJ3B-B211-RSL05T135-1
  • Series: 1000 Base T Right Angle RJ45 Jack
  • Gender: RJ45 Female Connector
  • Positions/ loads of contacts : 8P8C ( RJ45 , Ethernet )
  • Mounting type : Through hole
  • Latch Orientation: Right Angle (Side Entry)
  • LED indicator : Yes Yellow Green

Specfication:

Part Number:　 MJ3B-B211-RSL05T135-1
Product Family: 1000 Base T RJ45 Connector
Overview: RJ45 1x1 8P8C Right Angle 1000 Base T RJ45 Connector Blue Housing
Description: 8 core 1x1 ports Right Angle 1000 Base T RJ45 Jack connector, Shielded with EMI Finger
　 Operating temprature range: -40℃-70℃　
　　 　　　　　　
General
Series: 1000 Base T RJ45 Connector Jack
Numbers of ports: 1x1　
Orientation: Right Angle ( Side entry)　
Pin type: THT solder　
Positions/ Loaded contacts 8P8C　
Latch: Tab up　
LEDs: Yes
Shielded: Shielded
Jack Height: 13.4mm　
Magnetic: Yes
Performance category:

1000 Base T
Power over Ethernet(PoE): Non-PoE　　　　　
Physical
Color-Resin: Black
Durability(mating cycles max): 750　
Material Metal: Phosphor bronze　
Resin: Liquid crystal polymer　
Plating termination: Gold Flash　
Plating min- mating: 6u"/15u"/30u" optional　
Net Weight: TBA　
PCB: FR4　
PCB locator: Yes　
PCB retention: None　
PCB retaining post: T-post　
PCB Thickness- Recommended 1.6mm　
Packaging type: Tray　
Temperature range: -40℃-70℃　
RoHS compliant YES, RoHS AND Halogen-Free　　　
Electrical
Current rating: 1.5AMPS　
Voltage rating: 125V AC　
Insulation Resistance: 500MΩ mini　
Withstand voltage: 1000V RMS 60Hz　
Contact Resistance: 50mΩ Max　
Grounding to PCB: YES　
Grounding to Panel: YES　

Documents:

*** CLICK HERE TO DOWNLOAD THE DRAWING

HELING Right Angle RJ45 Connector Female Receptacle is designed as simple, flexible and low profile for ethernet connectivity applications, in particular, the network interface system etc.
