Female To Female RJ11 Phone Jack 90 Degree Socket 6P6C Top Entry
Female To Female RJ11 Phone Jack 90 Degree Socket 6P6C Top Entry
Female To Female RJ11 Phone Jack 90 Degree Socket 6P6C Top Entry
Female To Female RJ11 Phone Jack 90 Degree Socket 6P6C Top Entry
Specifications
Brand Name :
CSAK
Model Number :
CSAK-5301(5311-66-200-001-L)
Certification :
RoHs , UL , SGS
Place of Origin :
GuangDong
MOQ :
300pcs
Price :
Price to be negotiated in person
Payment Terms :
T/T
Supply Ability :
1000,000pcs/Month
Delivery Time :
24-30 work days
Packaging Details :
100pcs/Tray
Name :
RJ11 Jack
Type :
90 Degree Socket
CURRENT RATING :
1.0 AMP
Contact Terminal :
6P6C
Insert Port :
Top Entry
STORAGE :
-40℃~80℃
Description

RiteAV Black RJ11 RJ12 Phone Keystone Jack Female 90 Degree Socket

  • Phone Jack Female to Female
  • Color: Black
  • Use with RJ11 or RJ12 6p6c or 6p4c phone line connectors
  • Plug one phone line cord into front and one cable into back
  • Fits standard keystone wall plates

Product Name

Type Housing&Insert Material
RJ11 JACK RJ11 Female PBT UL94V-0
Mating/Unmating Force Retention Strength Operating Life
2.2KG.F.MAX 7.7KG.F Min Between Jack and Plug 600cycles min
No.Port Color Contact Terminal
1port Black 6P6C
Opening Direction Product Size Insert Port
Tab-up 15.88mmX13.45mmX16.38mm Top Entry

MATERIAL:
1. HOUSING MATERIALGLASS FILLED PLYESTER UL94V-0PBT, NYLON
2. HOUSING COLORBLACK OR OTHERS
3. CONTACT MATERIALPHOSPHOR BRONZE φ0.46mm
4. PLATING: GOLD PLATING OVER NICKEL.GOLD PLATING
THICKNESS 1.5u"/3u"/6u"/15u"/30u"/50u"

specifications

1. VOLTAGE RATING: 125 VAC RMS.
2. CURRENT RATING: 1.0 AMP
3. CONTACT RESISTANCE: 30 MILLIOHMS MAX.
4. INSULATION RESISTANCE500 MEGOHMS MIN ＠500 VDC
5. DIELECTRIC WITHSTANDING RESISTANCE: 1000 VAC RMS.50Hz 1MINUTE

MECHANICAL
1. DURABILITY750 CYCLES MIN
2. PCB RETENTION PRE-SOLDER: 1 LB MIN
ENVIRONMENTAL
1. STORAGE :-40℃~80℃
