1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
Specifications
Brand Name :
CSCE
Model Number :
55D-238821101
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Place of Origin :
Shenzhen,China
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
D/P, L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
150K pcs/day
Delivery Time :
7-10 days
Packaging Details :
Tray in Carton
Application :
PCB
Gold plating :
3u"
Business type :
Manufacturer
Housing :
PBT/Nylon
Contact resistance :
50 Milliohms max
Contact :
8C
Description

1x4 Multi-Port Jack 6P6C 8p8c Female RJ11 RJ12 RJ45 Socket Connector

Product Specification:

Specification: RJ45 Shielded Jack Cross Part NO: 55D-238821101
Mounting: Thru-hole R/A Samples: Available 2-3 Pcs
Latch: Tab up Files: PDF/3D/ISG/Stp/Step/Datasheet

Product Details:

Current Rating 1.5A
Voltage Rating 125v
Contact Resistance 30milliohm Max
Withstand Voltage 1000V AC 50Hz or 60Hz,1MIN.
Insulation Resistance 500 MΩ MIN @ 500V DC.
Mating/Unmating Force 2.2KG.F MAX.
Retention Strength 7.7KG.F MIN Between Jack And Plug
Operating Life 750 Cycles MIN.
Operation Temperature -40℃ to +85℃
Storage Temperature -40℃ to +85℃
Insert Material UL94V-0
Contact Material DiamererI 0.46mm C51000(QSn4-0.3)Phosphor Bronze
Shield 0.20mm Thichness H65Y Brass Nickel Plated

CSCE Corporate Policy

• The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction

Through Continuous Improvements In Quality, Delivery And Service

• CSCE Is Committed To And Expects Quality Performance From Every Employee

• The Company Standard Is Defect-Free Products And Services.

Why Choose us

• Free Samples. •Delivery Time 1-2 Weeks.

Yueqing Electronic RJ45 Connector 14 years of Manufacturing Experience.

Factory

• We have over 3000 workers.

• The area of Yueqing is 1800,000 square meters.

• Yueqing Shichuang Electronics Co.,Ltd have owns 3 factory in Yueqing,Shenzhen,Jiangxi.

Quality

• Lean production management.

• 100% Tested (Not Just Batch Tested).

• Quality Guarantee:5 Years.

Certification

• ISO 9001:2000,

• ISO14001

• Active Environmental Policy.

Have R&D dept

• OEM Service Offered, Design Service Offered.

• Engineer Can Design Products As You Need,Developer Tooling As Customer Require.

FAQ

*Q: Can I get samples from you?

A: We are honored to offer you samples for quality check.

*Q: What parts are manufactured by you?

A: All of frame parts are manufactured by us.

*Q: What's the leading time? (How long do you need to prepare my goods?)

A: 5 days for sample orders. 15 days for mass production orders (based on different quantities)

*Q: How long do I need to wait before my goods arrive?

A: 3-5 days for international express. 5-7 days for air transportation, 15-30 days for sea transportation.

Product Drawing

1×4 6P6C 8P8C Female Shielded RJ45 Jack For PCB
