75 Ohms Right Angle SMA Connector , SMA Female PCB Mount Jack Size L28*H14.7mm
75 Ohms Right Angle SMA Connector , SMA Female PCB Mount Jack Size L28*H14.7mm
75 Ohms Right Angle SMA Connector , SMA Female PCB Mount Jack Size L28*H14.7mm
75 Ohms Right Angle SMA Connector , SMA Female PCB Mount Jack Size L28*H14.7mm
Specifications
Brand Name :
CSCE
Model Number :
SC1-F000000012
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Place of Origin :
Shenzhen,China
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
150K pcs/day
Delivery Time :
7-10 days
Packaging Details :
Tray in Carton
Vswr :
≤1.5
Impedance :
75Ω
Product name :
F Female
Frequency range :
0-2Ghz
plating :
NI
size :
L28mm*H14.7mm
Description

SC1-F000000012 75 Ohms, F Right-Angle Printed Circuit Board Jack Receptacle

Quick Details:

Specification: Antennas Cross Part NO: SC1-F000000012
Mounting: solder Samples: Available 2-3 Pcs

Product Specification:

Impedance 75 ohm
Frequency Range 0-2 GHz
Working Voltage 250 VRMS max
Dielectric Withstanding Voltage 500 VRMS min
VSWR 1.SI5 max
Center Contact 5 Milliohms max
Outer Contact 2 Milliohms max
Insulator Resistance 1000 Megohms min

Product Material:

Body,Metal Parts Brass per QQ -B-626 Nick 70 micro-inches
Male Brass per QQ-B-626 Gold 3 micro-inches
Female Phosphor Bronze Gold 3 micro-inches
Insulators Teflon,Delrin None
Crimp Ferrules Annealed Brass Nickel 70 micro-inches
Clamp Gaskets Synthetic rubber None

Why Choose Us

World’s Leader Supplier Of Integrated antennas Connector

Production Ability

The company’s own injection molding, stamping and automated assembly plant, a professional automated production and testing equipment, the company has established an independent laboratory.

Our Team

We can turn your vision into reality. Thank you for visit. For any further information, please feel free to contact us.

Product application:

Products are widely used in radio, television, remote sensing toys, mobile communication, wireless Internet access, logistics express tracking services, etc.

Product Drawing:

75 Ohms Right Angle SMA Connector , SMA Female PCB Mount Jack Size L28*H14.7mm
