90 Degree Flat Pin RJ11 Modular Jack
90 Degree Flat Pin RJ11 Modular Jack
90 Degree Flat Pin RJ11 Modular Jack
90 Degree Flat Pin RJ11 Modular Jack
90 Degree Flat Pin RJ11 Modular Jack
90 Degree Flat Pin RJ11 Modular Jack
Specifications
Brand Name :
CSCE
Model Number :
57B-16621X01
Certification :
CE,ISO14001,CE/RoHs/ISO9001
Place of Origin :
Shenzhen ， China
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, , Western Union, MoneyGram
Supply Ability :
150K pcs/day
Delivery Time :
7-10 days
Packaging Details :
Tray in Carton
Type :
rj11
Application :
Networking
Connector type :
RJ11
Usage :
Telephone wire
Gender :
Female
Description
5722 Series Unshislded 6Pin 6Contact Single Port RJ11 Modular Jack DIP 90 Degree Flat Pin

Production Ability

The company’s own injection molding, stamping and automated assembly plant, a professional automated production and testing equipment, the company has established an independent laboratory.

Product Details:

Voltage rating 125 VAC RMS
Current rating 1.5 AMP
Contact resistance 30 Milliohms max
Insulation resistance 500 Megohms min @ 500 VDC
Dielectric strength 1000 VAC rms 50Hz or 60Hz,1min
Insert material UL94V-0
Contact material Phosphor bronze T=0.35mm
Plating Contact area-selective gold plating
Mating force 2.2KG.F max
Retention strength 7.7KG.F min between jack and plug
Operation life 600 Cycles min
Storage Temperature ﹣40℃ to +85℃
Operation Temperature ﹣40℃ to +85℃

Product Specification:

Specification: RJ11 Modular Jack Cross Part NO: 57B-16621X01
Mounting: Thru-hole R/A Samples: Available 2-3 Pcs

CSCE Corporate Policy

• The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction

Through Continuous Improvements In Quality, Delivery And Service

• CSCE Is Committed To And Expects Quality Performance From Every Employee

• The Company Standard Is Defect-Free Products And Services.

OEM Services

For high-quality, high reliability and reasonable price RJ45 network connector products,and more than the word’s top 500 OEM manufacturers recognized.

Competitive Advantage:

CSCE has various types of appearance and many kinds of internal schematic products,high quality, customer firstly ,100% test, zero defect, short lead time are our best advantages ,Our products have been exported to all over the world and got a good reputation, If you have any questions,please do not hesitate to contact us by email or Trade Manager. We 'll get back to you in 24 hours.

Product Drawing:

90 Degree Flat Pin RJ11 Modular Jack
