Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A
Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A
Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A
Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A
Specifications
Brand Name :
CSCE
Model Number :
59B-32880131X01S
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Place of Origin :
Shenzhen ， China
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, , Western Union, MoneyGram
Supply Ability :
150K pcs/day
Delivery Time :
7-10 days
Packaging Details :
Tray in Carton
Gender :
Female
Type :
RJ45
Application :
PCB
Voltage rating :
125vac
name :
RJ45 Modular Jack
Operating temperature :
-40℃ to +85℃
Description
Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A




Product Specification:

Specification:RJ45 Modular JackCross Part NO:59B-32880131X01S
Mounting:Thru-hole R/ASamples:Available 2-3 Pcs
Latch:Tab upFiles:PDF/3D/ISG/Stp/Step/Datasheet




Product Details:

1. Current Rating1.5A
2. Voltage Rating125v
3. Contact Resistance30milliohm Max
4. Withstand Voltage1000V AC 50Hz or 60Hz,1MIN.
5. Insulation Resistance500 MΩ MIN @ 500V DC.
6. Mating/Unmating Force2.2KG.F MAX.
7. Retention Strength7.7KG.F MIN Between Jack And Plug
8. Operating Life750 Cycles MIN.
9. Operation Temperature﹣40℃ to +85℃
10. Storage Temperature﹣40℃ to +85℃
11. Housing MaterialPBT
12. Contact MaterialPhosphor Bronze
13. Contact Mating Area PlatingGold/3u"/6u"/15u"/30u"



Competitive Advantage
14years production experience,
300staff,
100% test
Flexible delivery time


Why choose us:

  1. Equipment and manufacturing ability for mould
  2. Competitive price , and in time delivery well-selling in both domestic and foreign markets
  3. Acquired the ISO9001-2000 quality management system certification , ISO14001 environmental management system and UL certification .
  4. Specializes in the development , design , production and sale of communication network connectors .



FAQ

How to develop a new product base on an idea?
A: Tell us what you want, Then we will design it for free.

How about OED,ODM?
A: 14 years experiences in OEM,ODM.

How to reduce your risk?
A: Check the sample before order.

How about the after-sale service?
A: Just tell us the problem after you receive the products.
Then we’ll help you deal with it together.



Product Drawing:

Female 2 x 2 RJ45 Ethernet Jack 8 Pin 8 Contact RJ45 Modular Jack Current Rating 1.5A
