1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE
Specifications
Place of Origin :
China
Brand Name :
LINK-PP
Certification :
UL,ROHS,Reach,ISO
Model Number :
PTC0001-01
MOQ :
50/500/1000
Price :
Supportive
Packaging Details :
50pcs/tray,1200pcs/carton
Delivery Time :
Stock
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Specifications :
PTC0001-01
P-N :
LPJF0017CNL
TAB direction :
Down
RoHS Compliant :
yes
Ethernet :
1x 10/100
Samples :
Available
Description
1x Magnetic RJ45 Jack PTC0001-01 | LPJF0017CNL LAN 10/ 100BASE

Feature - LAN 10/ 100BASE T Low Profile RJ45 Jack With Magnetic module
♦ Designed for network interface card application.
♦ Designed to meet IEEE802.3u requirement.
♦ Available in all turn ratios used by LAN IC manufactures.
♦ Primary center taps available for additional EMI reduction.
♦ Simplest magnetic component to place and route on PCB.
♦ Contains termination resistors , magnetic and connector.
♦ Conserves PCB space.
♦ PTC0002-01
♦ PTC0003-01
♦ PTC0004-01
♦ PTC0006-01
♦ PTC0007-01
♦ PTC0008-01
♦Shield ……………… 0.25mm Thickness C5191 with Nickel Plated
♦Housing……………Standard Material PBT , Glass Filled Polyester UL94V-0
Standard Color Black
♦Contact Pin………..Plastic : NyLon-46 Glass Filled , UL94V-0 , Standard Color Black
Pin : Phosphor Bronze Wire t0.35*w0.45
Plating : Phosphor Bronze Gold Plating Over Nickel
Applications:
Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem
Competitive Advantage:
2600 staff,
100% test
Flexible delivery time
