Two Ports RJ45 Connector LED Integrated 100M Magnetics LPJ17087AENL
Two Ports RJ45 Connector LED Integrated 100M Magnetics LPJ17087AENL
Two Ports RJ45 Connector LED Integrated 100M Magnetics LPJ17087AENL
Two Ports RJ45 Connector LED Integrated 100M Magnetics LPJ17087AENL
Specifications
Place of Origin :
China
Brand Name :
LINK-PP
Certification :
UL,RoHS,Reach,ISO
Model Number :
LPJ17087AENL
MOQ :
50/500/1000/60K
Price :
$0.11-$24
Packaging Details :
Tray
Delivery Time :
Stock
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
180K/Month
Spec Mfg :
RJMG12103XX80NA
Alternate :
LPJ17087AENL
Magnetics :
2x1 Port Integrated
Application :
HUB, PC card, Switch, Router etc
Mounting :
Side Entry (Right Angle)
Cross rf :
LPJ17087AENL = RJMG12103XX80NA
Description
Two Ports RJ45 LED Integrated 100M Magnetics Coss RJMG12103XX80NA
1.10/100M stacked RJ45 connector LPJ17087AENL
2. Doube RJ45 Jack with magnetic modules
3.Shielded RJ45 Modular Jack LINK-PP
4.Router, PC Mainboard, SDH, PDH
Two Ports RJ45 Connector LED Integrated 100M Magnetics LPJ17087AENL
Description:
2X1 10/100M RJ45 Magjack with/without leds, meeting IEEE 802.3u
1. Product Type Features:
1) Product Type = Connector
2) Jack Type = RJ45
3) Profile = Standard
4) PCB Mounting Orientation = Side Entry (Right Angle)
2. Mechanical Attachment:
1) Jack Configuration = 1 x 1
3. Electrical Characteristics:
1) Shielded = Yes
4. Termination Related Features:
1) EMI Finger - Bottom = Without
2) Termination Method = Solder
5. Body Related Features:
1) Port Configuration = Single/Multi
2) EMI Fingers -Top and Sides = With/ Without
3) Latch Orientation = Standard - Latch Down
4) PCB Tail Length
6. Contact Related Features:
1) Preloaded = Yes
2) Contact Termination Type = Through Hole/Surface Mount
7. Housing Related Features:
1) Connector Style = Jack
8. Industry Standards:
1) RoHS/ELV Compliance = RoHS compliant, ELV compliant
2) Lead Free Solder Processes = Wave solder capable to 240°C,
Wave solder capable to 260°C, Wave solder capable to 265°C
3) RoHS/ELV Compliance History = Always was RoHS compliant
9. Identification Marking:
1) Left LED Color (Position #1) = Green - 250 ohm resistor
2) Right LED Color (Position #2) = Green - 250 ohm resistor
10. Conditions for Usage:
1) Applies To = Printed Circuit Board
2) Environmental Conditions = Office / Premises
3) Operating Temperature (°C ) = 0 - 70/-40 - +85
Applications:
Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem
Competitive Advantage:
21 years production experience,
1100 staff,
100% test
Flexible delivery time
