PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack
PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack
PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack
PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack
Specifications
Place of Origin :
China
Brand Name :
LINK-PP
Certification :
UL,ROHS,Reach,ISO
Model Number :
J0026D21BNL
MOQ :
50/500/1000
Price :
Supportive
Packaging Details :
50pcs/tray,1200pcs/carton
Delivery Time :
Stock
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Product Name :
J0026D21BNL
Made In China :
SM-LPJ0026ABNL
Interface :
10/100Mbps
RoHS Compliant :
yes
LED indicator :
Flexible
Samples :
Free Available
Description

PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack

Quick Details
1.10/100 Base-T
2.1X1 Tab-down
3.Through hole RJ45 modular jack
4.21.3mm length RJ45 Magjack

J0026D21BNL ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio(%%P2%):
TX=1CT:1 RX=1CT:1CT
2.Inductance OCL: 350uH MIN
@100KHz,0.1V,8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 1-65MHz
4.Return Loss:
-20dB MIN @ 1-10MHz
-16dB MIN @ 10-30MHz
-12dB MIN @ 30-60MHz
-10dB MIN @ 60-100MHz
5.Cross talk:
-40dB MIN @ 1-30MHz
-35dB MIN @ 30-60MHz
-30dB MIN @ 60-100MHz
6.Common Mode Rejection:
-30dB MIN @ 1-50MHz
-20dB MIN @ 50-150MHz
7.Hipot Test: 1500Vrms MIN
8.Operating Temperature Range: 0℃ TO 70℃.

PCB Connector J0026D21BNL Hipot 1500Vrms RJ45 10/100BT Magnetic Jack
