Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
Specifications
Brand Name :
LINK-PP
Model Number :
749013011A
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
Guangdong,China
MOQ :
400/2000/10K/25K
Price :
$0.06-$3.2
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3KK/Month
Delivery Time :
Stock
Packaging Details :
T&R
Specification :
749013011A
Cross PN :
LP2019ANL
Turns Ratio :
1CT:1CT
Mounting :
Surface Mount
Ethernet :
1x10/100 Mbps Power
Isolation Voltage :
1500Vrms
Capability :
720mA DC
Archivi Disponibil :
PDF/3D/ISG/Stp/Step/Datasheet
Description
Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
  1. SPECIFICATIONS
    REACH Compliant Yes
    EU RoHS Compliant Yes
    Status Active
    Transformer Type DATACOM TRANSFORMER
    Application SIGNAL
    Approvals UL
    Insertion Loss 1.1 dB
    Isolation Voltage 1500.0 V
    Manufacturer Series 749013011A , LINK-PP 749013011A Equivalent
    Mounting Feature SURFACE MOUNT
    Operating Temperature-Min -40.0 Cel
    Operating Temperature-Max 85.0 Cel
    Packing Method TAPE & REEL
    Physical Dimension 12.7mm x 8.8mm x 6.35mm
    Primary Inductance 350.0 µH
    Sub Category Other Transformers
    Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
    Turns Ratio (Np:Ns) 1:1
    Height 6.35 mm
    Length 12.7 mm
    Width 8.8 mm

Transformers Audio & Signal 10/100 Base-T SMD 1 Port Cross 749013011A
