LPJ19205DNL SMT POE Rj45 Jack , 1x 10/100Mbps IEEE 802.3af Power over Ethernet
LPJ19205DNL SMT POE Rj45 Jack , 1x 10/100Mbps IEEE 802.3af Power over Ethernet
Specifications
Brand Name :
LINK-PP
Model Number :
LPJ19205DNL
Certification :
ISO9001,SGS,UL,CE,REACH
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/25K
Price :
$0.09-$1.85
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3000000/Month
Delivery Time :
Stock
Packaging Details :
150PCS/Reel,6Reels=900PCS=35.5*35.5*35cm=10KG
Specification :
LPJ19205DNL
Part Number :
LPJ19205DNL
Munafactuer :
LINK-PP
Ethernet :
10/100Mbps Power Over Ethernet
Mounting :
SMD
Samples :
Free
Description
LPJ19205DNL SMT POE Rj45 Jack , 1x 10/100Mbps IEEE 802.3af Power over Ethernet

  • IEEE 802.3af Power over Ethernet (PoE) Rj45
  • 1x Surface Mount Rj45 Connector
  • Power Over Ethernet Rj45 Magnetics Module
  • LPJ19205DNL 1 x 10/100 Mbit Ethernet
  • Lan Connectors Rj45 Without Led

SMT Rj45 Power Over Ethernet IEEE802.3af
Electrical Specifications @25℃
1.Turns Ratio:
TX=1CT:1CT RX=1CT:1CT
2.Inductance:350uH Min
@ 100KHz,0.1Vrms,8mADC.
3.Insertion Loss:
1-100MHz: -1.2dB Max
4.Return Loss(dB Min):
1-30MHz:-16 40MHz:-14
50MHz:-13 60-80MHz:-12
5.Crosstalk(dB Min):
30MHz:-43 60MHz:-37
100MHz:-33
6.DCMR(dB Min):
30MHz:-50 60MHz:-43
100MHz:-35
7.Hipot: 1500Vrms @ 60Hz 1 MIN
8.Operating Temperature: 0℃～+70℃.		 LPJ19205DNL SMT POE Rj45 Jack , 1x 10/100Mbps IEEE 802.3af Power over Ethernet
