LPJG27011AENL 2x2 Gigabit Power Over Ethernet+ Rj45 Magnetic Jack IEEE802.3at
LPJG27011AENL 2x2 Gigabit Power Over Ethernet+ Rj45 Magnetic Jack IEEE802.3at
Specifications
Brand Name :
LINK-PP
Model Number :
LPJG27011AENL
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/60K
Price :
$0.11-$24
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
180K/Month
Delivery Time :
Stock
Packaging Details :
Tray
Part No :
LPJG27011AENL
Specification :
LPJG27011AENL
Ethernet :
4x10/100/1000mbps Power
Mounting :
Thru-hole
Termination :
Solder
Samples :
Available
Description
LPJG27011AENL 2x2 Gigabit Power Over Ethernet+ Rj45 Magnetic Jack IEEE802.3at
  • 4x Magnetic Rj45 Gigabit Ethernet
  • LPJG27011AENL # LINK-PP Rj45 10/100/1000 Full Power Over Ethernet Plus
  • R/A Shield Connector POE+ Stacked RJ45
  • 6u,15,30u,50u Gold Plating
  • 2x2 Port Ethernet Rj-45 Port

1.Turns Ratio(±2%):

1CT∶1CT
2.Inductance: 350uH Min
@0.1MHz,0.1V,8mA DC Bias
3.Insertion Loss:
1-100MHz:-1.0dB Max
4.Return Loss(dB Min):
1-30MHz:-18 30-60MHz:-16
60-100MHz:-12
5.Crosstalk(dB Typ):
1-30MHz:-40 30-60MHz:-35
60-100MHz:-30
6.Common to Mode Rejection(dB Typ):
1-50MHz:-30 50-150MHz:-20
7.Hipot: 1500Vrms
8.Operating Temperature: -40℃～+85℃.

 LPJG27011AENL 2x2 Gigabit Power Over Ethernet+ Rj45 Magnetic Jack IEEE802.3at
LPJG27011AENL 2x2 Gigabit Power Over Ethernet+ Rj45 Magnetic Jack IEEE802.3at
