3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M 24 Pins SMD XFMR
3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M 24 Pins SMD XFMR
Specifications
Brand Name :
LINK-PP
Model Number :
LP6004NL
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
Guangdong,China
MOQ :
400/2000/10K/25K
Price :
$0.06-$3.2
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3KK/Month
Delivery Time :
Stock
Packaging Details :
T&R
Specification :
LP6004NL
Part Number :
LP6004NL
Interface :
Gigabit
Mounting :
Surface Mounting
Pins :
24 Pins
Samples :
Free Available
Archivi Disponibili :
PDF/3D/ISG/Stp/Step/Datasheet
Description
3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M , 24Pins SMD XFMR
  • 3500V rms Isolation Transformer
  • 5000V Max Isolation Transformer high-voltage
  • LINK-PP LP6004NL Single Port XFMR
  • Gigabit 10/100/1000Mbps , 24Pins SMD
  • Lan Discrete Transformer Modules
3500V rms Isolation
Electrical Specifications @25℃
1.Insertion Loss:
1-100MHz:-1.0dB MAX
2.Return Loss(dB MIN @100Ω):
1-30MHz:-18 40MHz:-18
50MHz:-16 60-80MHz:-12
100MHz:-10
3.Crosstalk(dB MIN):
30MHz:-45 60MHz:-40
100MHz:-35
4.DCMR(dB MIN):
30MHz:-43 60MHz:-37
100MHz:-33
5.Hipot: 3500V rms MIN
6.Operating Temperature: -40℃～85℃		 3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M 24 Pins SMD XFMR
3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M 24 Pins SMD XFMR 3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M 24 Pins SMD XFMR
3500V rms Isolation Transformer LP6004NL Gigabit 10/100/1000M , 24Pins SMD XFMR
