Rj45 1 x 10/100 Mbit Ethernet RJLD-302TC1 PCB Monted Ethernet Connector
Rj45 1 x 10/100 Mbit Ethernet RJLD-302TC1 PCB Monted Ethernet Connector
Specifications
Brand Name :
LINK-PP
Model Number :
RJLD-302TC1
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000/25K
Price :
$0.05-$1.28
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4200K-PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Specification :
RJLD-302TC1
Cross Part :
LPJ0014ABNL
Munafactuer :
LINK-PP
Ethernet :
10/100Mbps Ethernet
Port :
1x1
Samples :
Free
Description
Rj45 1 x 10/100 Mbit Ethernet RJLD-302TC1 PCB Monted Ethernet Connector

  • RJ45 connector-jack
  • RJLD-302TC1
  • 1 x 10/100 Mbit Ethernet
  • Lan connector Rj45
  • Lan Connectors Rj45 With Led Activity

◎ Fully shielded magnetics protect data from internally generated digital noise
◎ Reduces the overall length of the signal path for improved common mode performance
◎ Implements full common mode termination scheme with used and unused twisted pairs
◎ Meets IEEE802.3 Baseline Wander Compensation specification
◎ Integrates high voltage capacitor to chassis ground
◎ Supports all major transceivers with matched turns ration and complete integration of specified termination
◎ Design for 100BASE-TX Transmission over UTP-5 cable.
◎ Operating temp range: -40 ℃ ℃ to +85

Rj45 1 x 10/100 Mbit Ethernet RJLD-302TC1 PCB Monted Ethernet Connector Rj45 1 x 10/100 Mbit Ethernet RJLD-302TC1 PCB Monted Ethernet Connector
