LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED
LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED
Specifications
Brand Name :
LINK-PP
Model Number :
LPJE201AHNL
Certification :
ISO9001,SGS,UL,CE,REACH
Place of Origin :
GuangDong, China
MOQ :
50/500/1000/25K
Price :
$0.11-$12
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
208K/Month
Delivery Time :
Stock
Packaging Details :
Tray
Part No :
LPJE201AHNL
Specification :
LPJE201 Series
Category :
Cat5/5e
Mounting :
Thru-hole
Termination :
Solder
Samples :
Available
Description
LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED
  • 2x Rj45 8P8C
  • LPJE201AHNL # LINK-PP
  • R/A Shield Connector
  • 1.3U,3U,6u,15,30u,50u Gold Plating
  • 1x2 Dual Port Ethernet Port

PCB JACK Specification
1.Insulation Resistance:500MΩMIN @ 500 VDC
2.Withstanding Voltage:AC1000V 50Hz or 60Hz 1min.
3.Durability:600 Mating Circles MIN.
4.Gold Plating:(Gold Flash;1.5;3;6;15;30;50)u" inch
5.(1)Storage: -40℃ to +85℃
(2)Opertion: -40℃ to +85℃
(3)Wave solder temperture:230℃ to 250℃,5～10 Sec.

 LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED
LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED

LPJE201AHNL 1x2 rj45 Jack Dual port, Side Entry 8P8C R/A Shield With LED

LINK-PP 1x2 Port LPJE201 Series Available Part
LPJE201A47NL LPJE201A80NL LPJE201AWNL
LPJE201AGNL LPJE201AHNL LPJ27434AGNL
