13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL
13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL
Specifications
Brand Name :
LINK-PP
Model Number :
13F-39NL
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
Guangdong,China
MOQ :
400/2000/10K/25K
Price :
$0.06-$3.2
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3KK/Month
Delivery Time :
Stock
Packaging Details :
T&R
Specifications :
13F-39NL
Part Number :
LP0013NL
Hi-pot :
1500Vrms
OCL :
350uh min
Speed :
10/100 Base-TX
Application :
NIC/HUB/Switch/Router/PC System/Printer/Server
Temperature Range :
0℃ To +70℃
Professional Certificate :
SGS/ISO9001:2008/UL/ISO 14001:2004/REACH168
Description
13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL

13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL 13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL
13F-39NL 10/100 Base-t Single Port SMD Ethernet Module Transformer LP0013NL

Part Number : 13F-39NL
1.Turns Ratio(±3%):
TX=1CT:1CT RX=1CT:1CT
2. Intuctance OCL :
350uH MIN @ 100KHz 0.1V
3. DCR : 1.2Ω MAX
4. Insertion Loss(dB MIN):
1-100MHz:-1.1
5. Return Loss(dB MIN):
1-30MHz:-18
30-40MHz:-14
40-50MHz:-13
60-80MHz:-12
6. Crosstalk(dB MIN):
1-30MHz:-40
60-100MHz:-35
7. Common To Common Mode Rejection:
1-30MHz:-40
30-60MHz:-35
80-100MHz:-30
8. Hi-Pot: 1500VRMS

9. Operating Temperature Range : 0℃ To 70 ℃
