LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
Specifications
Brand Name :
LINK-PP
Model Number :
7498011241
Certification :
ISO9001,SGS,UL,CE,REACH
Place of Origin :
GuangDong, China
MOQ :
600 PCS
Price :
Supportive&Competitive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3000000/Month
Delivery Time :
Stock
Packaging Details :
150PCS/Reel,6Reels/Carton,900PCS/Carton=35.5*35.5*35cm,Weight10KG
Specification :
7498011241
Cross PN :
LPJ19201BGNL
Ethernet :
10/100mpbs
Mouting :
SMD
Indicator :
LED
Samples :
Free Available
Description

LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector

  • LINK-PP # LPJ19201BGNL
  • SMT RJ45 Connector
  • Meets Network Adapter
  • RosH ,ISO9001,SGS,UL,CE,REACH
  • Cross 7498011241

Electrical Specification @25℃


1.Turns Ratio(±2%):
TX=1CT:1CT RX=1CT:1CT
2.OCL: 350uH Min
@100KHz,100mV,8mA bias current
3.Insertion Loss(dB Max):
1-80MHz:-1.0 100MHz:-1.2
4.Return Loss(dB Min @100Ω):
1-60MHz:-14 60-100MHz:-10
5.Crosstalk: 1-80MHz:-35dB Min
6.IR Reflow peak temperature: 260 degc.
7.Isolation Voltage: 1500Vrms Min
8.Operating Temperature: 0℃～70℃.

 LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
LPJ19201BGNL SMT RJ45 Jack Cross 7498011241 Surface Mouting Connector
