1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer
Specifications
Brand Name :
LINK-PP
Model Number :
TG110-E050N5LF
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
Guangdong,China
MOQ :
400/2000/10K/25K
Price :
$0.06-$3.2
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3KK/Month
Delivery Time :
Stock
Packaging Details :
T&R
Midcom PN :
TG110-E050N5LF
Made In China :
SM-LP1198NL
Family :
ULTRA ™ Family of Transformers
Pins :
16Pins
Port :
Single Port Transformer
Hipot :
1500V
Archivi Disponibili :
PDF/3D/ISG/Stp/Step/Datasheet
Description

1500Vrms Hi-Pot TG110-E050N5LF SMD Single Port 10/100BASE-TX Transformer

TG110-E050N5LF Halo

Trader Part Number

TG110-E050N5LF

Price Break

Unit Price

Extended Price

1-5

A

-

10-50

B

-

100-500

C-1

-

1,000-2,500

Supportive

-

5,000

Dynamic

Dynamic

10,000

Dynamic

Dynamic

50,000

Negotiable

Negotiable

100,000

Negotiable

Negotiable

500,000

Negotiable

Negotiable

Made in China

SM-LP1198NL

Manufacturer

LINK-PP China

Description

SMD Single Port 10/100 Transformer

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

2,000 PCS or 4 weeks

TG110-E050N5LF Electrical Specification @25℃

1.OCL: 350uH Min
@100KHz,0.2V,With 8mA DC BIAS
2.Turns Ratio(%%P5%):
TX=1CT:1CT RX=1CT:1CT
3.Insertion Loss:
0.3-100MHz:-1.1dB Max
4.Return Loss(dB Min):
0.3-30MHz:-18 40MHz:-16
50MHz:-14.5 60-80MHz:-12
5.Crosstalk(dB Min):
0.3-60MHz:-42 60-100MHz:-35
6.Common Mode Rejection(dB Min):
0.3-30MHz:-40 60MHz:-35
80-100MHz:-30
7.Isolation Voltage: 1500Vrms
8.Operating Temperature: -40℃～+85℃.

1500Vrms Hi-Pot TG110-E050N5LF , SMD Single Port 10/100BASE-TX Transformer

1500Vrms Hi-Pot TG110-E050N5LF SMD Single Port 10/100BASE-TX Transformer
