Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds
Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds
Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds
Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds
Specifications
Brand Name :
LINK-PP
Model Number :
5-6605301-1
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Midcom PN :
5-6605301-1
Made In China :
SM-LPJ00XXABNL
Family :
Rj45 Female Connector
Interface :
10/100Mbps
LED :
Design Flexible
Samples :
Available
Description

Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds

5-6605301-1
Trader Part Number
5-6605301-1 Rj45
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
-
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
Negotiable
Negotiable
100,000
Negotiable
Negotiable
500,000
Negotiable
Negotiable
Made in China
SM-LPJ00XXABNL
Manufacturer
LINK-PP China
Description
Gigabit Ethernet Connector
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
2,000 PCS or 4 weeks

5-6605301-1 ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio(±3%):
(P1-P2):(J1-J2)=1:1
(P7-P8):(J3-J6)=1:1
2.Inductance:
(P1-P2): 350uH MIN @100KHz 0.1V,8mA DC Bias
(P7-P8): 350uH MIN @100KHz 0.1V,8mA DC Bias
3.Insertion Loss:
-1.2dB MAX @ 0.1-80MHz
4.Return Loss:
-18dB MIN @ 1-30MHz
-12dB MIN @ 30-80MHz
5.Cross talk:
-35dB TYP @ 0.1-100MHz
6.Common To Common Mode Attenuation:
-30dB TYP @ 30-100MHz
7.Hipot Test: 1500VAC
8.Operating Temperature Range: 0℃ TO 70℃

Rj45 With Magnetics 5-6605301-1 10/100 Ethernet Schematic Shielded With Leds
