Belfuse SI-53021-F Rj45 Modular Jack Pinout With Integrated Magnetics
Belfuse SI-53021-F Rj45 Modular Jack Pinout With Integrated Magnetics
Specifications
Brand Name :
LINK-PP
Model Number :
SI-53021-F
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Designe PN# :
SI-53021-F
Made In China :
SM-LPJ1141AWNL
Family :
Rj45 Network Port
Interface :
10/100Base-TX
LED :
Flexible
Samples :
Available
Description

Belfuse SI-53021-F Rj45 Modular Jack Pinout With Integrated Magnetics

Belfuse SI-53021-F
Trader Part Number
SI-53021-F
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
-
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
Negotiable
Negotiable
100,000
Negotiable
Negotiable
500,000
Negotiable
Negotiable
Made in China
SM-LPJ1141AWNL
Manufacturer
LINK-PP China
Description
 10/100M Modular Rj45
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
200,000 PCS or 4 weeks

SI-53021-F ELECTRICAL SPECFICATIONS @25℃
1.Turn Ratio:
TX=1CT:1CT RX=1CT:1CT
2.Inductance OCL: 350uH MIN
@ 100KHz/0.1V 8mA DC Bias
3.Insertion Loss:
1.0-100MHz:-1.0dB MAX
4.Return Loss(dB MIN):
1-30MHz: -18 30-60MHz:-15
60-80MHz: -12 80-100MHz:-10
5.Cross talk(dB MIN):
30MHz: -40 60MHz: -35
100MHz:-30
6.Common Mode Rejection(dB MIN):
30MHz: -40 60MHz: -35
100MHz:-30
7.Hipot Test: 1500Vrms
8.Operating Temperature Range: -40℃ TO +85℃
