HX1332CNLT Power Over Ethernet Transformer for Medical Safety
HX1332CNLT Power Over Ethernet Transformer for Medical Safety
HX1332CNLT Power Over Ethernet Transformer for Medical Safety
HX1332CNLT Power Over Ethernet Transformer for Medical Safety
Specifications
Brand Name :
LINK-PP
Model Number :
HX1332CNLT
Certification :
UL,RoHS,Reach,ISO
Place of Origin :
Guangdong,China
MOQ :
400/2000/10K/25K
Price :
$0.06-$3.2
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3KK/Month
Delivery Time :
Stock
Packaging Details :
T&R
PN :
HX1332NL
RoHS :
YES
Turns Ratio :
1CT : 1CT
Temperature :
-40°C ~ 85°C
Inductance :
350 uH
Mounting Style :
SMD/SMT
Description

100 Base-T High Isolation Transformer Specifications:

Part Number

HX1332CNLT

Speed

10/100 BASE-T
Mounting SMT

Number of Channels/Ports

SINGLE

Application - LAN

Ethernet(PoE)
PoE 30W 2Pair

Operation Temperature Range

-40 to +85℃
Storage Temperature -50°C to 125°C

AutomDX

YES
Turns Ratio 1:01

Hi-POT RATING

4KV-2PPP
Safety Insulation REINFORCED
Isolation Voltage 4000V

Working Voltage

400V

Construction

OPEN FRAME

Package Height (mm)

10.6 mm

Package Length (mm)

25.4 mm

Package Width (mm)

17.2 mm

Category

Pulse Transformers

Packaging

Reel
Unit Weight 4 g

LINK-PP LAN Transformer

LINK-PP Ethernet transformers are RoHS-compliant and qualified by major PHY suppliers. These Ethernet transformer modules are optimized for all major LAN transceivers. They offer electrical circuit isolation meeting IEEE 802.3 standards while preserving signal integrity essential for demanding applications.

Features & Benefits:

  1. Data rates: 100/1000/2.5G/5G/10GBASE-T.
  2. IEEE 802.3 compliance up to 10G.
  3. High isolation up to 6kV.
  4. Enhanced reliability (Carrier Class & AEC-Q200).
  5. Available in single, dual, quad packages, with SMT, THR & BGA options.
  6. Extended temperature range: -40°C to +85°C.
  7. 2P/4P PoE/PoE+/PoE++ capable up to 140W maximum power.
  8. PINs ranging from 12 to 96, supporting custom configurations.


HX1332CNLT Power Over Ethernet Transformer for Medical Safety
HX1332CNLT Power Over Ethernet Transformer for Medical Safety
