PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics
Specifications
Place of Origin :
DongGuan of China
Brand Name :
DGKYD
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
MOQ :
1 piece
Packaging Details :
Tray in Carton
Delivery Time :
10 days
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
100K pcs/day
Model Number :
KRJ-060SHWNL
Price :
Please contact us to get the latest price.
LEDS/EMI fingers :
custom,as your need
Application :
lan,bridge,PC,router,usb hub network rj45
Gender :
Female RJ45
Feature :
High performance,magnetic
Product Name :
RJ45 Ethernet Jack
RJ45 Suitable :
for CAT5&6 Ethernet Cable or UTP
Description

Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics

PCB Surface Mount RJ45 Ethernet Connector Shielded with Internal MagneticsPCB Surface Mount RJ45 Ethernet Connector Shielded with Internal MagneticsPCB Surface Mount RJ45 Ethernet Connector Shielded with Internal Magnetics

Material specifications:

  • Plastic core:Glass fiber filler PBT Black(UL94V-0)
  • Contact:gold pin0.35mm thick phos bronze plated nickel then with 6u’gold
  • PCB Terminal:Phosphor bronze ,Tail-Tin over Nickl
  • Housing:Phenolic, PBT Black (UL94V-0)
  • Metal shell:Copper Alloy ,Tin and Nickel plated

Applications:

• Integrated RJ45 connector main used to :

• 10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,

optical transceiver,IP phone, internet set-top box, internet camera, net bridge, computer, telecommunication,MODEM,HomePNA,DSL／ADSL and so on.

Competitive Advantage:

Keyouda has various types of appearance and many kinds of internal schematic products,high quality,

customer firstly,100% test, 0 defect, short lead time are our best advantages
