Specifications
Place of Origin :
DongGuan of China
Brand Name :
DGKYD
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number :
KRJ-201QGYGNL
MOQ :
1 piece
Packaging Details :
Tray in Carton
Delivery Time :
10 days
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
100K pcs/day
Price :
Please contact us to get the latest price.
Performance Category :
1000 BASE-TX
Port Configuration :
Ganged two port
Product Name :
Cat RJ45 connector
Port Orientation :
Side Entry
Description

1000BASE 2Port Tab Down Transformer RJ45 Modular Jack for CAT6

P/N:KRJ-201QGYWEL

Descriptions:

  • 10/100/1000Base-Tx RJ45 2 port 1X2 Vertical with LEDS with side entry
  • Double port 1X2 Tab-Down RJ45 with internal magnetics
  • Internal magnetics are 100% electrically tested for HI-POT and functionality
  • Suitable for CAT5&6 fast Ethernet Cable or better UTP
  • 350uHminimum OCL with 8mA bias current
  • High performance for maximum EMI suppression
  • Minimum 1500Vrms isolation per IEEE 802.3 requirement
  • ROHS-6 peak wave solder temperature rating 260℃
  • Operating temperarure range :0℃ to +70℃
  • Storage temperature range :-40℃ to +85℃
  • Number of positions:10
  • Number of contacts loaded:8
  • Shieded:YES
  • Rohs compliant
  • Length:21.3mm
  • LEDS:YES
  • EMI finger:NO
  • LEFT LED:Green,RIGHT LED:Yellow
  • Usage:KRJ-201QGYWENL

1000 BASE ganged 2 Port cat6 RJ45 Modular Jack with internal transformer RoHS compliance1000 BASE ganged 2 Port cat6 RJ45 Modular Jack with internal transformer RoHS compliance1000 BASE ganged 2 Port cat6 RJ45 Modular Jack with internal transformer RoHS compliance
