Specifications
Place of Origin :
DongGuan of China
Brand Name :
DGKYD
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number :
DGKYD-56SYGZNL
MOQ :
1 piece
Packaging Details :
Tray in Carton
Delivery Time :
10 days
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
100K pcs/day
Price :
Please contact us to get the latest price.
Speed :
CAT 3/5/6
Port :
single port
Shield :
Yes
Transformer :
Without transformer
Mount Type :
PCB type
Latch :
Tab up
Description

Single Port RJ45 Modular Jack Without Transformer, Cat6 Shielded Connectors 8p8c

Single Port RJ45 shielded jack without transformer,10/100/1000BASE 8p8c connector

Descrition:

  • 1X1 Single port RJ45 Modular jack without transformer
  • tap-up rj45 connector with led right angle
  • Insertion Force:2.2KG.F.max
  • Retention Strength;7.7KG.Fmin between jack and plug
  • Durabbilith:600mating cycles min
  • Operating temperarure range :-40℃ to +85℃
  • Storage temperature range :-40℃ to +85℃
  • Number of positions:8
  • Number of contacts loaded:8
  • Shield:YES
  • Rohs compliant(GP)
  • Length:15.75mm
  • LEDS:Left/YELLOW,Right/GREEN

Applications:

• Integrated RJ45 connector main used to :

• 10/100/1000M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical

transceiver,IP phone, internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,

HomePNA,DSL／ADSL and so on.
