One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver
Specifications
Place of Origin :
DongGuan of China
Brand Name :
DGKYD
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number :
KRJ-339PWDENL
MOQ :
1 piece
Packaging Details :
Tray in Carton
Delivery Time :
10 days
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
100K pcs/day
Price :
Please contact us to get the latest price.
Performance :
1000Mb
PoE :
PoE / PoE+ / PoE++
Current Rating :
1.5 A (maximum) @ 25° C
Voltage Rating :
150 VAC (maximum)
Description

One Port Rj45 Transformer , power over ethernet 1000m Integrated 10 Pin Rj45 For Fiber Optic Transceiver

One Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic TransceiverOne Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic TransceiverOne Port PoE Rj45 Transformer , 1000m Integrated 12 Pin Rj45 For Fiber Optic Transceiver

  • Plastic Materials: UL 94V-0 rated
  • Contact Material: Copper Alloy
  • Contact Plating: 50 micro-inch selective hard gold
  • Mechanical dimensions comply with IEC 61076-3-110
  • Electrical performance as defined by IEC 60603-7-71
  • Operating Temp: -40°C to 85°C
  • Cable and jack connector system designed for freq. up to 1,000 MHz
  • Interface compatible with Nexans GG45 Connector System
  • Patented plug design allows for port density equivalent to standard RJ45 connectors
  • Plug design includes integral slim line strain relief with built in latch protection
  • Uses data pair isolation technology to achieve high frequency performance
  • Look and feel of an RJ45 connector but with beyond 10GBase-T performance capabilities
