Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack
Specifications
Place of Origin :
DongGuan of China
Brand Name :
DGKYD
Certification :
RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Model Number :
KRJ-56S8P8C1X2NL
MOQ :
1 piece
Packaging Details :
Tray in Carton
Delivery Time :
10 days
Payment Terms :
T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :
100K pcs/day
Price :
Please contact us to get the latest price.
Product Name :
2-Port RJ45 Jack
Shieded :
YES
Positions :
8
Contacts :
8
Application :
set-top box,internet camera,net bridge
Speed :
Cat 3/5
Description

10 / 100 / 1000 Base-Tx 1 x 2-Port RJ45 Modular Jacks Rohs Compliant

Economical Cost Shield 1x2 Tab Up Double Port Ethernet Socket Rj45 Modular Jack

  • 10/100/1000Base-Tx RJ45 2 port 1X2 Side Entry (Right Angle) without LED
  • High performance for maximum EMI suppression
  • Minimum 1500Vrms isolation per IEEE 802.3 requirement
  • ROHS-6 peak wave solder temperature rating 260℃
  • Operating temperarure range :-40℃ to +85℃
  • Storage temperature range :-40℃ to +85℃
  • Number of positions:8
  • Number of contacts loaded:8
  • Shieded:YES
  • Rohs compliant
  • LEDS:NO

Material specifications:

  • Plastic core:Glass fiber filler PBT Black(UL94V-0)
  • Contact:gold pin0.35mm thick phos bronze plated nickel then with 0.6u’gold
  • PCB Terminal:Phosphor bronze ,Tail-Tin over Nickl
  • Housing:Phenolic, PBT Black (UL94V-0)
  • Metal shell:Copper Alloy ,Tin and Nickel plated

Applications:

• Integrated RJ45 connector main used to :

• 10/100/1000M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,

optical transceiver, IP phone,internet set-top box,internet camera,net bridge,computer,

telecommunication,MODEM,HomePNA,DSL／ADSL and so on.
