8P8C Female 2X4 8 Port RJ45 Jack Connector With LED Light
8P8C Female 2X4 8 Port RJ45 Jack Connector With LED Light
8P8C Female 2X4 8 Port RJ45 Jack Connector With LED Light
8P8C Female 2X4 8 Port RJ45 Jack Connector With LED Light
Specifications
Brand Name :
PHCONN
Model Number :
phc1059
Certification :
UL
Place of Origin :
CHINA
MOQ :
100 pcs
Price :
1.1-1.5 USD
Payment Terms :
L/C, T/T, D/P
Delivery Time :
5-15 work days
Packaging Details :
Blister box packaging products, carton packaging Blister box
Type :
Multi Type
Gender :
Female
Application :
PCB,Audio & Video,Communication,Panel Mount,PRINTER
Product name :
RJ45 Cat5e Cat6 Cat6a Metal Boot Commscope Keystone Jack
Ports :
8 Ports
Transmission rate :
10/100Mbps
Durability :
750 CYCLES MIN
Insulation resistance :
500 MEGOHMS MIN @500V DC
Description

8 Port RJ 45 8P8C Female 2X4Port Jack Connector with LED Light

ELECTRICAL

CURRENT RATING:

1.5 AMPS

VOLTAGE RATING:

125 VAC RMS

INSULATION RESISTANCE:

1000 MΩ Min. @ 500V DC

WITHSTAND VOLTAGE:

1000 V AC OR 1500V DC RMS @0.5mA 50Hz / 60Hz 1 Minute

CONTACT RESISTANCE:

1XN ROUND PIN 35 mΩ Max./ 1XN FLAT PIN 45 mΩMax./

2XN ROUND PIN 40 mΩ Max./ 2XN FLAT PIN 50 mΩMax.

MECHANICA

MATING/UNMATING FORCE:

22N / 2.27kg Max

RETENTION STRENGTH:

57.83N Min./ 30N Min.

DURABILITY:

750 MATING/UNMATING CYCLES Min.

ENVIRONMENTAL

OPERATION TEMPERATURE:

-40℃~+85℃ / -20℃~+70℃

STORAGE TEMPERATURE:

-10℃~+40℃ RELATIVE HUMIDITY<80%

MATERIAL

HOUSING:

PBT/PA46/PA66/ABS/PC, UL94V-0 OR UL94V-2

TERMINAL:

DIAMETER 0.46mm/THICKNESS 0.35mm PHOSPHOR BRONZE,SELECTIVE GOLD PLATING OVER NICKEL

GOLD PLATING:

Fu inch , G/F inch, 3u inch, 6u inch,15u inch, 30u inch, 50u inch

Company Introduction

Dongguan PENGHUI Electronic Co., Ltd. is a wholesale company which produces and sells

excellent electronic connectors and adaptors.It was established in 2014. The company provides

customized products and OEM services. New styles and designs come out every month.The

company has skilled technology and updated machines, as well as professional design service

team, think what you think, use for you, and look forward to meeting you.
