Multi-core Cable And Ribbon Cable Stripping And Crimping Machine RS-6800
Multi-core Cable And Ribbon Cable Stripping And Crimping Machine RS-6800
Specifications
Brand Name :
RKENS
Model Number :
RS-6800
Place of Origin :
China
Name :
Multi-core Cable And Ribbon Cable Stripping And Crimping Machine
For :
Multi-core cable , ribbon cable
Usage :
Strip and crimp
Language :
English
Description

Multi-core Cable And Ribbon Cable Stripping And Crimping Machine

Intro:

This machine is for 0-20 multi-core cables, and ribbon cables. Stripping and crimping can be finished at same time. The stripping parts and crimping parts are sepated. Applicator can be changed easily. Stripping depth can be adjusted.

Suitable:

It works forstripping and crimping flat ribbon cables, multi-core cables.

Parameters:

Model RS-6800 multi-core cable, ribbon cable stripping and crimping machine
Power Supply 220V 50HZ/60HZ
Rated Power 0.75KW
Size L690xW450XH1250MM
Weight 118KG
Available wires Multi-core cables with 0-20 cores, ribbon cable, electric wires
Strip length 0-25mm
Press stroke 30MM
Press capacity 2.0T
Suitable Applicator Vertical or horizontal applicators

Features:

1. Stripping and tapping terminals are completed at one time, which is convenient and fast. It adopts frequency conversion control to achieve soft start and soft stop without mechanical loss.

2. The cassette die and stripping parts are independent, the card die can be replaced easily, the stripping depth can be adjusted, and the production adaptability is strong.

3. Independent peeling, riveting terminal operation, automatic and manual operation, and each action time can be adjusted according to the specifications of the wire and the terminal.

4. The whole machine adopts PLC program control, man-machine interface 7-inch touch screen, pneumatic and air valve, durable.

5. Proprietary dander recovery device, clean operation.

Multi-core Cable And Ribbon Cable Stripping And Crimping Machine RS-6800

Multi-core Cable And Ribbon Cable Stripping And Crimping Machine RS-6800

Machine video:
